贝加莱本地I/O主站控制器3EX350.6

贝加莱8LT扭矩电机特点：
高扭矩8LT电机
8LT系列三相同步电机是专为需要高动态特性和定位精度以及紧凑型结构应用而开发的的永磁电子换向同步电机。

NdFeB永磁体
正弦EnDat编码器作为反馈单元
现在可用功能安全编码器
三相星型连接
输电系统无弹性
良好的转子构造，使转动惯量***小化，保证了优异的动态特性
高负载能力/峰值扭矩
扭矩脉动低
无机械传输元件受输电系统支配，因此具有高可用性
寿命长，除轴承外所有电机部件免磨损
定子产生的功耗通过外壳直接转移到法兰上
预紧的深沟球轴承两端密封并油脂润滑
完整的电机产品线，堵转扭矩范围从50 Nm至1020 Nm
采用两个SpeedTEC圆形插头进行电气连接
通过减少机械损失实现节能
由ACOPOS伺服驱动器或ACOPOSmulti驱动系统控制

8LT三相同步电机不能直接与电源连接，它们只能与ACOPOS伺服驱动器或ACOPOSmulti驱动系统组合起来进行工作！

统一的连接技术，预接线电缆和嵌入式参数芯片实现动力传输系统的即插即用。接头处可以旋转，为接线提供了***大的灵活性。

8LT三相同步电机所有相关的机械和电气数据及信息都存储于EnDat编码器中。因此，对于用户来说无需在伺服驱动上做任何设置。当编码器和伺服驱动器相连时，上电后电机将会被自动识别。电机将额定参数和限制参数传送至伺服驱动。驱动自动选择能够控制电机所要用到的***佳电流限制参数和控制参数。用户只要负责优化速度和位置控制参数。贝加莱Automation StudioTM 软件中集成的调试环境为用户提供支持。
另外，这还有助于使常规的维护更加简便，电机更换时无需再花时间设置参数。

贝加莱8LT扭矩电机冷却类型/结构A：
贝加莱8LT扭矩电机冷却类型/结构A尺寸9：
8LTA93.ee003ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 3, nominal speed 300 rpm
8LTA93.ee005ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 3, nominal speed 500 rpm
8LTA93.ee010ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 3, nominal speed 1000 rpm
8LTA94.ee003ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 4, nominal speed 300 rpm
8LTA94.ee005ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 4, nominal speed 500 rpm
8LTA94.ee010ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 4, nominal speed 1000 rpm
8LTA95.ee003ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 5, nominal speed 300 rpm
8LTA95.ee005ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 5, nominal speed 500 rpm
8LTA95.ee010ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 5, nominal speed 1000 rpm
8LTA96.ee003ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 6, nominal speed 300 rpm
8LTA96.ee005ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 6, nominal speed 500 rpm
8LTA96.ee010ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 6, nominal speed 1000 rpm
8LTA97.ee003ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 7, nominal speed 300 rpm
8LTA97.ee005ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 7, nominal speed 500 rpm
8LTA97.ee010ffgg-0
Synchronous motor, self-cooling / ISO flange, size 9, length 7, nominal speed 1000 rpm

贝加莱8LT扭矩电机冷却类型/结构A尺寸C：
8LTAC3.ee001ffgg-0
Synchronous motor, self-cooling / ISO flange, size C, length 3, nominal speed 100 rpm
8LTAC3.ee003ffgg-0
Synchronous motor, self-cooling / ISO flange, size C, length 3, nominal speed 300 rpm
8LTAC3.ee005ffgg-0
Synchronous motor, self-cooling / ISO flange, size C, length 3, nominal speed 500 rpm
8LTAC4.ee001ffgg-0
Synchronous motor, self-cooling / ISO flange, size C, length 4, nominal speed 100 rpm
8LTAC4.ee003ffgg-0
Synchronous motor, self-cooling / ISO flange, size C, length 4, nominal speed 300 rpm
8LTAC4.ee005ffgg-0
Synchronous motor, self-cooling / ISO flange, size C, length 4, nominal speed 500 rpm
8LTAC5.ee001ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 5; Rated speed 100 rpm;
8LTAC5.ee003ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 5; Rated speed 300 rpm;
8LTAC5.ee005ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 5; Rated speed 500 rpm;
8LTAC6.ee001ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 6; Rated speed 100 rpm;
8LTAC6.ee003ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 6; Rated speed 300 rpm;
8LTAC6.ee005ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 6; Rated speed 500 rpm;
8LTAC7.ee001ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 7; Rated speed 100 rpm;
8LTAC7.ee003ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 7; Rated speed 300 rpm;
8LTAC7.ee005ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 7; Rated speed 500 rpm;
8LTAC8.ee001ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 8; Rated speed 100 rpm;
8LTAC8.ee003ffgg-0
Synchronous motor, self cooling / ISO flange; Size C; Length 8; Rated speed 300 rpm;

贝加莱8LT扭矩电机冷却类型/结构J：
贝加莱8LT扭矩电机冷却类型/结构J尺寸9：
8LTJ93.ee003ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 3, nominal speed 300 rpm
8LTJ93.ee005ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 3, nominal speed 500 rpm
8LTJ93.ee010ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 3, nominal speed 1000 rpm
8LTJ94.ee003ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 4, nominal speed 300 rpm
8LTJ94.ee005ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 4, nominal speed 500 rpm
8LTJ94.ee010ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 4, nominal speed 1000 rpm
8LTJ95.ee003ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 5, nominal speed 300 rpm
8LTJ95.ee005ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 5, nominal speed 500 rpm
8LTJ95.ee010ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 5, nominal speed 1000 rpm
8LTJ96.ee003ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 6, nominal speed 300 rpm
8LTJ96.ee005ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 6, nominal speed 500 rpm
8LTJ96.ee010ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 6, nominal speed 1000 rpm
8LTJ97.ee003ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 7, nominal speed 300 rpm
8LTJ97.ee005ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 7, nominal speed 500 rpm
8LTJ97.ee009ffgg-0
Synchronous motor, external cooling / ISO flange, size 9, length 7, nominal speed 900 rpm

贝加莱8LT扭矩电机冷却类型/结构J尺寸C：
8LTJC3.ee003ffgg-0
Synchronous motor, external cooling / ISO flange, size C, length 3, nominal speed 300 rpm
8LTJC3.ee005ffgg-0
Synchronous motor, external cooling / ISO flange, size C, length 3, nominal speed 500 rpm
8LTJC3.eeA08ffgg-0
Synchronous motor, external cooling / ISO flange, size C, length 3, nominal speed 80 rpm
8LTJC4.ee003ffgg-0
Synchronous motor, external cooling / ISO flange, size C, length 4, nominal speed 300 rpm
8LTJC4.ee005ffgg-0
Synchronous motor, external cooling / ISO flange, size C, length 4, nominal speed 500 rpm
8LTJC4.eeA08ffgg-0
Synchronous motor, external cooling / ISO flange, size C, length 4, nominal speed 80 rpm
8LTJC5.ee003ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 5; Rated speed 300 rpm;
8LTJC5.ee005ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 5; Rated speed 500 rpm;
8LTJC5.eeA08ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 5; Rated speed 80 rpm;
8LTJC6.ee003ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 6; Rated speed 300 rpm;
8LTJC6.ee005ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 6; Rated speed 500 rpm;
8LTJC6.eeA08ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 6; Rated speed 80 rpm;
8LTJC7.ee003ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 7; Rated speed 300 rpm;
8LTJC7.eeA08ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 7; Rated speed 80 rpm;
8LTJC8.ee003ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 8; Rated speed 300 rpm;
8LTJC8.eeA08ffgg-0
Synchronous motor, separately cooled / ISO flange; Size C; Length 8; Rated speed 80 rpm;
贝加莱本地I/O主站控制器3EX350.6

分布式和灵活性
就拓扑结构而言，ACOPOSmotor模块可以采用简单的线型和树型结构。在线型结构中，会自动分配节点号。而需要设置地址时无需打开外壳。
使用一根混合电缆实现与驱动组的连接。它包含了运行ACOPOSmotor以及POWERLINK网络相关的所有电源线和信号线。
高效的IP65防护等级使ACOPOSmotor模块可以直接被安装在机器上。控制柜则只包含电源，高功率逆变模块和其它必要的机电组件。这样很容易实现模块化的机器架构和可选的机器功能，因为它们可以轻松地利用混合电缆连接 – 必要的电源 – 至机器主线。
将X67模块直接连到ACOPOSmotor模块上对于模块化机器工程而言也是十分理想的。这为机器模块实现独立且可测试的生产单元铺平了道路。
贝加莱本地I/O主站控制器3EX350.6


7XV108.50-11 远程阀岛连接 8路用于25-芯DSUB多芯连接,X2X Link,电隔离
7XV108.50-12 远程阀岛连接 8路用于25-芯DSUB多芯连接,X2X Link,电隔离
7XV108.50-51 远程阀岛连接 8路用于25-芯DSUB多芯连接,X2X Link,电隔离,IP67防护等级
7XV116.50-01 远程阀岛连接 16路用于25-芯DSUB多芯连接,X2X Link
7XV116.50-11 远程阀岛连接 8路用于25-芯DSUB多芯连接,X2X Link,电隔离
7XV116.50-12 远程阀岛连接 16路用于25-芯DSUB多芯连接,X2X Link,电隔离
7XV116.50-21 远程阀岛连接 16路用于25-芯DSUB多芯连接,X2X Link,电隔离
7XV116.50-51 远程阀岛连接 8路用于25-芯DSUB多芯连接,X2X Link,电隔离,IP67防护等级
7XV124.50-11 远程阀岛连接 24路用于25-芯DSUB多芯连接,X2X Link,电隔离
7XV124.50-12 远程阀岛连接 24路用于25-芯DSUB多芯连接,X2X Link,电隔离
7XV124.50-51 远程阀岛连接 24路用于25-芯DSUB多芯连接,X2X Link,电隔离,IP67防护等级
7XX410.50-1 远程I/O带X2X Link,24 VDC;3x绝对式编码器/增量式编码器输入;3 x AO +/-10 VDC,12-bit; 3 x DI, 24 VDC,漏式
7XX410.50-1 远程I/O带X2X Link接口,24 VDC;8路热电偶输入(其中2路可以通过软件独立将其配置为模拟量输入+/-10V 12-bit/ 用于测量电阻0-4kOhm);12xDO 2 A 50%, 4xDO 2 A 100%, 24 VDC
7XX415.50-K02 远程I/O带X2X Link接口,24 VDC;2路全桥张力输入；4xDA 0.5 A, 4xDA 2 A; 24 VDC; 16xDE, 24 VDC，漏式/源式，3个事件计数器 /1个增量式编码器/1路门/周期测量和1个事件计数器
7XX426.50-1 远程I/O带X2X Link接口,24 VDC; 8xDI, 24 VDC,漏式/源式,2个事件计数器/1路增量式编码器/1路门/周期测量 4xDO 2A, 50%, 4xDO 2A, 24 VDC;4xAI端口,4.5V, 14-bit; 1xAI 0-10V 12-bit; 3xAO, +/-10 V, 12-bit
7XX436.50-1 带X2X Link接口的远程I/O,24 VDC; 8xDI, 24 VDC,漏式/源式,2个事件计数器/1路增量式编码器/1路门/周期测量 4xDO 0,5A, 4xDO 2A, 24VDC; 4xAI, +/-10 V, 12-bit,2路模拟量输入可作为KTY10/PT1000输入,4xAO, +/-10V, 12-bit
7XX408.50-1 带X2X Link接口的远程I/O,24 VDC; 8xDI, 24 VDC,漏式/源式,2个事件计数器/1路增量式编码器/1路门/周期测量12xDO 0.A, 4xDO 2A, 24 VDC;带PWM功能的2路输出(2A)
7CX408.50-1 远程I/O带CAN接口,24 VDC;1个CAN接口,电隔离,能联网,16xDI,24 VDC,漏式;2个事件计数器/1个增量式编码器或1路门/周期测量;12xDO 0.4 A, 4xDO 2 A, 24 VDC,2路DO带PWM功能
7CX436.50-1 远程I/O带CAN接口,24 VDC;1个CAN接口,电隔离,能联网,16xDI,24 VDC,漏式;2个事件计数器/1个增量式编码器或1路门/周期测量;4xDO 0,4 A, 4xDO 2 A, 24 VDC, 2 DO带PWM功能,4 AI, +/-10 V, 12-bit + sign,2路模拟量输入可用作KTY10/PT1000输入,4 AO, +/-10 V, 12-bit
7EC021.60-1 嵌入式控制系统,x86 100 MHz Intel-compatible,16MB DRAM, 32 kB SRAM, CompactFlash, CAN, Profibus DP, X2X Link, Ethernet, RS232
7EC020.60-2 嵌入式控制系统,x86 100 MHz Intel-compatible,32MB DRAM, 32 kB SRAM, CompactFlash, CAN, X2X Link, Ethernet, RS232
7EC020.61-2 嵌入式控制低系统，x86 100 MHz Intel-compatible,32MB DRAM, 32 kB SRAM, CompactFlash, CAN, X2X Link, Ethernet, RS232, ARNC0

X20CP3486 X20 CPU, Celeron 650, 64 MB DRAM, 1 MB SRAM, 可更换内存条:  CompactFlash,SFlb3个X20 IF模块插槽SFlb2个USB接口,1个RS232接口,1个Ethernet(10/100 Base-T)接口,1个ETHERNET Powerlink接口(EPL框架,协议支持),另购程序内存.
X20CP1486 X20 CPU, Celeron 650, 64 MB DRAM, 1 MB SRAM, 可更换内存条:  CompactFlash,SFlb1个X20 IF模块插槽SFlb2个USB接口,1个RS232接口,1个Ethernet(10/100 Base-T)接口,1个ETHERNET Powerlink接口(EPL框架,协议支持),另购程序内存.
X20CP3485 X20 CPU, Celeron 400, 32 MB DRAM, 1 MB SRAM, 可更换内存条:  CompactFlash,SFlb3个X20 IF模块插槽SFlb2个USB接口,1个RS232接口,1个Ethernet(10/100 Base-T)接口,1个ETHERNET Powerlink接口(EPL框架,协议支持),另购程序内存.
X20CP1485 X20 CPU, Celeron 400, 32 MB DRAM, 1 MB SRAM, 可更换内存条:  CompactFlash,SFlb1个X20 IF模块插槽SFlb2个USB接口,1个RS232接口,1个Ethernet(10/100 Base-T)接口,1个ETHERNET Powerlink接口(EPL框架,协议支持),另购程序内存.
X20CP3484 X20 CPU, Celeron 266, 32 MB DRAM, 1 MB SRAM, 可更换内存条:  CompactFlash,SFlb3个X20 IF模块插槽SFlb2个USB接口,1个RS232接口,1个Ethernet(10/100 Base-T)接口,1个ETHERNET Powerlink接口(EPL框架,协议支持),另购程序内存.
X20CP1484 X20 CPU, Celeron 266, 32 MB DRAM, 1 MB SRAM, 可更换内存条:  CompactFlash,SFlb1个X20 IF模块插槽SFlb2个USB接口,1个RS232接口,1个Ethernet(10/100 Base-T)接口,1个ETHERNET Powerlink接口(EPL框架,协议支持),另购程序内存.
X20CP0292 X20 CPU,紧凑型CPU μP 25,750 KByte SRAM,3.4 MB FlashPROM,RS232和CAN支持紧凑型CPU底座,1个Ethernet接口(100 Base-T)
X20CP0291 X20 CPU,紧凑型CPU μP 16,100 KByte SRAM,512 KB FlashPROM,RS232和CAN支持紧凑型CPU底座,1个Ethernet接口(100 Base-T)
X20CP0201 X20 CPU,紧凑型CPU μP 16,100 KByte SRAM,512 KB FlashPROM,RS232和CAN支持紧凑型CPU底座
X20BC0043 X20总线控制现场总线接口模块,1个CANopen接口,状态显示器LEDs,另购1xTB2105端子排
X20BC0053 X20总线控制现场总线接口模块,1个DeviceNet接口,状态显示器LEDs,另购1xTB2105端子排
X20BC0063 X20总线控制现场总线接口模块,1个Profibus DP接口,状态显示器LEDs,9-芯DSUB连接
X20BC0073 X20总线控制现场总线接口模块,1个CANopen接口,状态显示器LEDs,另购1xTB2105端子排
X20BC0083 X20总线控制现场接口,ETHERNET Powerlink接口(EPL框架,协议支持),集成2x hub. 状态显示器LEDs,2 x RJ45连接
X20BC0087 X20总线控制现场接口,Modbus TCP接口,集成2x switch,状态显示器LEDs,2xRJ45连接
X20BM01 X20电源底板模块，将内部I/O电源和左侧相隔离
X20BM11 X20 I/O底板模块,与内部I/O电源连接
X20BB22 X20紧凑型CPU底座,适用于紧凑型CPU和CPU电源模块,集成RS232接口,X20连接,X20锁定板(左和右),包括X20AC0SL1/X20AC0SR1
X20BB27 X20紧凑型CPU底座,适用于紧凑型CPU和CPU电源模块,集成RS232和CAN接口, X20连接,X20锁定板(左和右),包括X20AC0SL1/X20AC0SR1
X20PS9500 为紧凑型CPU和内部I/O,X2X Link供电的电源模块
X20BB80 X20总线控制器底座,适用于总线控制现场接口模块和电源模块,X20连接
X20PS9400 X20电源模块为总线控制器,内部I/O,X2X Link供电
X20TB06 X20标准6芯端子
X20TB12 X20标准12芯端子
X20BR9300  X20总线接收(X2X Link),可以为内部I/O,X2X Link总线供电
X20BT9100  X20总线中继模块(X2X Link)
X20PS2100 X20电源模块为内部I/O供电
X20PS2110 X20电源模块为内部I/O供电,集成超小型保险丝
X20PS3300 X20电源模块为内部I/O,X2X link供电
X20PS3310 X20电源模块为内部I/O,X2X link供电,集成超小型保险丝
X20DI2371 X20数字量输入模块,2个输入量,24 VDC,漏式,可配置的输入滤波,3线连接技术
X20DI2372 X20数字量输入模块,2个输入量,24 VDC,源式,可配置的输入滤波,3线连接技术
X20DI2377 X20数字量输入模块,2个输入量,24 VDC,漏式,可配置的输入滤波,2线连接技术  50KHz
X20DI2653 X20数字量输入模块,2个输入,100-240 VDC,3线连接技术
X20DI4371 X20数字量输入模块,4个输入量,24 VDC,漏式,可配置的输入滤波,3线连接技术
X20DI4372 X20数字量输入模块,4个输入量,24 VDC,源式,可配置的输入滤波,3线连接技术
X20DI4653 X20数字量输入模块,4个输入,100-240 VDC,2线连接技术
X20DI4760 X20数字量输入模块,4个NAMUR输入,8.05 VDC
X20DI6371 X20数字量输入模块,6个输入量,24 VDC,漏式,可配置的输入滤波,2线连接技术
X20DI6372 X20数字量输入模块,6个输入量,24 VDC,源式,可配置的输入滤波,2线连接技术
X20DI9371 X20数字量输入模块,12个输入量,24 VDC,漏式,可配置的输入滤波,1线连接技术
X20DI9372 X20数字量输入模块,12个输入量,24 VDC,源式,可配置的输入滤波,1线连接技术
X20DO2321 X20数字量输出模块,2个输出,24 VDC,0.5 A,3线连接技术
X20DO2322 X20数字量输出模块,2个输出,24 VDC,0.5 A,源式,3线连接技术
X20DO2649 X20数字量输出模块,2个继电器,转换触点,230 VAC / 5 A, 30 VDC / 5 A
X20DO4321 X20数字量输出模块,4个输出,24 VDC,0.5 A,3线连接技术
X20DO4322 X20数字量输出模块,4个输出,24 VDC,0.5 A,源式,3线连接技术
X20DO4331 X20数字量输出模块,4个输出,24VDC,2.0A,3线连接技术
X20DO4332 X20数字量输出模块,4个输出,24VDC,2.0A,源式,3线连接技术
X20DO4529 X20数字量输出模块,4个继电器,转换触点,115VAC/0.5A, 30VDC/1A
X20DO6321 X20数字量输出模块,6个输出,24VDC,0.5A,漏式,2线连接技术
X20DO6322 X20数字量输出模块,6个输出,24VDC,0.5A,源式,2线连接技术
X20DO6529 X20数字量输出模块,6个继电器,N.O. 触点,115VAC/0.5A, 30VDC/1A
X20DO8331 X20数字量输出模块,8个输出,24VDC,2.0A,源式,模块能够直接供电,1线连接技术
X20DO8332 X20数字量输出模块,8个输出,24VDC,2.0A,源式,模块能够直接供电,1线连接技术
X20DO9321 X20数字量输出模块,12个输出,24 VDC,0.5 A,漏式,1线连接技术
X20DO9322 X20数字量输出模块,12个输出,24VDC,0.5A,源式,1线连接技术
X20DM9324 X20数字量混合模块,8个输入端,24VDC,漏式,可配置的输入滤波器,4个输出端,24VDC,0.5 A,1线连接技术
X20AI1744 1个DMS输入,24-bit分辨率转换器,外部过滤器模型
X20AI2622 X20模拟量输入模块,2个输入端,±10 V / 0 to 20 mA / 4 to 20 mA,12-bit分辨率,可配置的输入滤波
X20AI2632 X67模拟量输入模块,2路输入,±10 V / 0 to 20 mA,16-bit分辨率,可配置的输入滤波
X20AI4622 X20模拟量输入模块,4个输入端,±10 V / 0 to 20 mA / 4 to 20 mA,12-bit分辨率,可配置的输入滤波
X20AI4632 X20模拟量输入模块,4路输入端,±10 V / 0 to 20 mA,16-bit分辨率，可配置的输入滤波
X20AO2622 X20模拟量输出模块,2路输出端,±10 V / 0 to 20 mA,12-bit分辨率
X20AO2632 X20模拟量输出模块,2路输出端,±10 V / 0 to 20 mA,16-bit分辨率
X20AO4622 X20模拟量输出模块,4路输出端,±10 V / 0 to 20 mA,12-bit分辨率
X20AO4632 X20模拟量输出模块,4路输出端,±10 V / 0 to 20 mA,16-bit分辨率
X20AT2222 X20温度输入模块,2个用于PT100,PT1000的阻抗测量输入,分辨率0.1K,3线连接技术
X20AT2402 X20温度输入模块,2路热电偶输入,类型J,K,N,S,分辨率0.1K
X20AT4222 X20温度输入模块,4个用于PT100,PT1000的阻抗测量输入,分辨率0.1K,3线连接技术
X20AT6402 X20温度输入模块,6路热电偶输入,类型J,K,N,S,分辨率0.1K
X20CM8281 X20通用混合模块,4个输出端,24VDC,漏式,1线连接技术,2路数字量输出,0.5 A,源式,1线连接技术, 1个模拟量输入,±10 V或0-20 mA/4-20 mA,12-bit分辨率,1个模拟量输出, ±10 V/0-20 mA,12-bit分辨率, 2个计数器可作为事件计数或门测量
X20CM8323 X20 PWM模块,8个机电负载数字量输出端,持续电流0.6A,电流峰值2A,电压监控,时间检测转换,状态指示LEDs
X20PS4951 X20电位计供电模块,电位计电压4x±10V
X20CM8281 X20通用混合模块,4个输出端,24VDC,漏式,1线连接技术,2路数字量输出,0.5 A,源式,1线连接技术, 1个模拟量输入,±10 V或0-20 mA/4-20 mA,12-bit分辨率,1个模拟量输出, ±10 V/0-20 mA,12-bit分辨率, 2个计数器可作为事件计数或门测量
X20CM8323 X20 PWM模块,8个机电负载数字量输出端,持续电流0.6A,电流峰值2A,电压监控,时间检测转换,状态指示LEDs
X20PS4951 X20电位计供电模块,电位计电压4x±10V
X20CM1941 X20旋变模块,14-bit旋变模块输入,ABR输出可达10-bit
X20DC1196 X20数字量计数器模块,1个通道ABR,5 V,250 kHz输入频率,4x倍
X20DC1198 X20数字量计数器模块,1个通道SSI,5 V,1MBit/s,32-bit
X20DC1396 X20数字量计数器模块,1个通道ABR,24V,100kHz输入频率,4x倍
X20DC1398 X20数字量计数器模块,1个通道SSI,24V,125MBit/s,32-bit
X20DC2190 X20数字量计数模块,超声波传感器,接口: EP启动/停止,DPI/IP,2个传感棒,4个路径附值
X20DC2396 X20数字量计数器模块,2个通道ABR,24V,100kHz输入频率,4x倍
X20DC2398 X20数字量计数器模块,2个通道SSI,24V,125MBit/s,32-bit
X20DC2395 X20数字量计数器模块,1 x SSI绝对式编码器,24 V,1 x ABR增量式编码器,24 V, 2 x AB增量式编码器,24 V, 4 x 事件计数器或2 x PWM
X20DC4395 X20数字量计数器模块,2 x SSI绝对式编码器,24 V,2 x ABR增量式编码器,24 V, 4 x AB增量式编码器,24 V,8 x 事件计数器或4 x PWM
X20IF1020 X20接口模块,1个RS232,max. 115.2 kBit/s,电气隔离
X20IF1030 X20接口模块,1个RS485/RS422,max. 115.2 kBit/s,电气隔离
X20IF1061 X20接口模块,1个Profibus DP主站,max.12 MBit/s, 输入数据max.3.5 KB和SFlb输出数据max. 3.5 KB，电隔离
X20IF1063 X20接口模块,1个Profibus DP从站接口,max.12 MBit/s,电气隔离
X20IF1072 X20接口模块,1个CAN接口,max.1 MBit/s,电气隔离,另购1 x TB2105端子排
X20IF1082 X20接口模块,1个ETHERNET Powerlink接口(EPL框架,协议支持),管理器或控制器功能,集成2x hub
X20IF1091 X20接口模块,1个X2X Link主站接口,电气隔离,另购1 x TB704端子排
X20IF2772 X20接口模块,2个CAN接口,max.1 MBit/s,电气隔离,另购2 x TB2105端子排
X20IF2792 X20接口模块,1个CAN接口, max.1 MBit/s,电气隔离,1个X2X Link主站接口,SFlb电隔离,另购1 x TB2105和1 x TB704端子排
X20CS1020 X20接口模块,1个RS232,max. 115.2 kBit/s
X20CS1030 X20接口模块,1 x RS485/RS422,max. 115.2 kBit/s
X20CS1070 X20接口模块,1 x CAN, max. 1 MBit/s, 收发双方都具备对象缓冲功能
X20ZF0000 X20空模块(没有功能)
贝加莱本地I/O主站控制器3EX350.6
