3IF786.9贝加莱接口模块

贝加莱8KS同步电机特点：
8KS三相同步电机
8KS系列三相同步电机是专为需要高动态特性和定位精度应用而开发的的永磁电子换向同步电机。

额定功率高达140 kW
风扇冷却并优化水冷
正弦EnDat编码器或旋变器作为反馈单元
可用功能安全编码器
三相星型连接
高负载能力/峰值扭矩
扭矩脉动低
高速时的高动态扭矩
寿命长，除轴承外所有电机部件免磨损
电源通过接线盒连接，编码器通过SpeedTEC或 ITEC圆形连接器连接
由ACOPOS伺服驱动器或ACOPOSmulti驱动系统控制

8KS三相同步电机不能直接与电源连接，它们只能与ACOPOS伺服驱动器或ACOPOSmulti驱动系统组合起来进行工作！

8KS三相同步电机可以配置各种不同的编码器系统。通常，它们配有Heidenhain EnDat 编码器。根据具体的应用，用户可以选择单圈或多圈光电式编码器。无需寻参过程或者附加测量系统便可运行。8KS三相同步电机也可以配置旋变器以适用于低精度和低速度的机械。

贝加莱8KS同步电机冷却类型C：
贝加莱8KS同步电机冷却类型C尺寸8：
8KSC82.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 1100 rpm;
8KSC82.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 1600 rpm;
8KSC82.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 2000 rpm;
8KSC82.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 2500 rpm;
8KSC82.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 3000 rpm;
8KSC84.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 1100 rpm;
8KSC84.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 1600 rpm;
8KSC84.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 2000 rpm;
8KSC84.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 2500 rpm;
8KSC84.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 3000 rpm;
8KSC85.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 1100 rpm;
8KSC85.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 1600 rpm;
8KSC85.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 2000 rpm;
8KSC85.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 2500 rpm;
8KSC85.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 3000 rpm;
8KSC86.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 1100 rpm;
8KSC86.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 1600 rpm;
8KSC86.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 2000 rpm;
8KSC86.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 2500 rpm;
8KSC86.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 3000 rpm;

贝加莱8KS同步电机冷却类型C尺寸9：
8KSC92.ee010ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 1000 rpm;
8KSC92.ee015ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 1500 rpm;
8KSC92.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 2000 rpm;
8KSC92.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 2500 rpm;
8KSC92.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 3000 rpm;
8KSC94.ee010ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 1000 rpm;
8KSC94.ee015ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 1500 rpm;
8KSC94.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 2000 rpm;
8KSC94.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 2500 rpm;
8KSC94.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 3000 rpm;
8KSC95.ee010ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 5, nominal speed 1000 rpm;
8KSC95.ee015ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 5, nominal speed 1500 rpm;
8KSC95.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 5, nominal speed 2000 rpm;
8KSC95.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 5, nominal speed 2500 rpm;
8KSC96.ee010ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 6, nominal speed 1000 rpm;
8KSC96.ee015ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 6, nominal speed 1500 rpm;
8KSC96.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 6, nominal speed 2000 rpm;

贝加莱8KS同步电机冷却类型D：
贝加莱8KS同步电机冷却类型D尺寸8：
8KSD82.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 1100 rpm;
8KSD82.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 1600 rpm;
8KSD82.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 2000 rpm;
8KSD82.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 2500 rpm;
8KSD82.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 3000 rpm;
8KSD84.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 1100 rpm;
8KSD84.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 1600 rpm;
8KSD84.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 2000 rpm;
8KSD84.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 2500 rpm;
8KSD84.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 3000 rpm;
8KSD85.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 1100 rpm;
8KSD85.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 1600 rpm;
8KSD85.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 2000 rpm;
8KSD85.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 2500 rpm;
8KSD85.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 3000 rpm;
8KSD86.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 1100 rpm;
8KSD86.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 1600 rpm;
8KSD86.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 2000 rpm;
8KSD86.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 2500 rpm;
8KSD86.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 3000 rpm;
3IF786.9贝加莱接口模块



大多数两相混合式步进电机有一个1.8°的步距角。除此之外，还有0.9°甚至小于0.45°的。较小的步距角往往会产生较差的扭矩曲线。只有支持微步的步进电机驱动器才能用于实现更高的定位精度。此外，高步进分辨率会产生出色的同心性，并且减少共振效应带来的潜在问题。

设定位置的精度取决于所施加的负载扭矩以及步进电机的制造精度。单步内的定位精度始终随负载和偏离角而定。但是，这决不能高于一个全步，因为不然的话电机会无法同步并丢失步。该负载角的***佳补偿方式是通过位置反馈。这就是为什么所有贝加莱步进电机都可选经济实惠的编码器的原因，这些编码器可以实现高达12 位的分辨率。因此，即使在相当大的负载扭矩下，定位精度也可以实现小于0.1°的角偏差。
3IF786.9贝加莱接口模块
特价工业贝加莱 B&R BR2003系统产品
7CP570.60-1 1) 2003系列CPU,Celeron 300, 64MB DRAM, 512KB SRAM, 24VDC, 15W供电,可更换应用存贮卡:CompactFlash,
1个aPCI插槽,1个USB接口,一个100 Base-T 100 Ethernet接口
7CP476-020.9 2) 2003系列CPU,可扩展,750KB SRAM, 1.5MB FlashPROM, 24VDC, 11.8W供电,1个RS232接口,1个CAN接口
7CP476-010.9 2003系列CPU,可扩展,750KB SRAM, 1.5MB FlashPROM, 24VDC, 12.15W供电,1个RS232接口,1个CAN接口
7CP476.60-1 2003系列CPU,750KB SRAM, 1.5MB Flash PROM, 24VDC, 12.5W供电,1个RS232和CAN接口:电隔离
7CP774.60-1 2003系列CPU,100KB SRAM,512KB FlashPROM,100-240VAC, 12.6W供电,1个RS232和CAN接口
7CP474.60-2 2003系列CPU,750KB SRAM,512KB FlashPROM,24VAC,12.6W供电,1个RS232和CAN接口
7CP770.60-1 2003系列CPU,100KB SRAM,256KB FlashPROM,100-240VAC,14W供电,1个RS232和CAN接口
7CP470.60-2 2003系列CPU,350KB SRAM,512KB FlashPROM,24VAC,14W供电,1个RS232和CAN接口
7CP430.60-1
7EX270.50-1 2003系列CAN总线控制器,24VDC, 4W供电,1个CAN接口,电隔离,可连接网络
7EX290.50-1 2003系列X2X Link总线控制器,24VDC,3.2W供电,1个X2X Link接口,电隔离
7EX470.50-1 2003系列CAN总线控制器,24VDC, 14.5W供电,2个CAN接口,电隔离,可连接网络
7EX770.50-1 2003系列CAN总线控制器,100-240VDC,14.5W供电,2个CAN接口,电隔离,可连接网络
7EX481.50-1 2003系列ETHERNET Powerlink总线控制器,1个ETHERNET Powerlink接口,24VDC,电隔离
7EX484.50-1 2003系列ETHERNET Powerlink总线控制器,4个ETHERNET Powerlink接口,24VDC,电隔离
7AF101.7 2003系列适配器模块,4个插槽,用于旋入式模块
7AF104.7 2003系列高速适配器模块,4个插槽,用于旋入式模块
7DI435.7 2003系列数字量输入模块,8路输入,24VDC, 1ms,漏式/源式
7DI439.7 2003系列数字量输入模块,16路输入,24VDC,1ms,漏式/源式
7DI439.72 2003系列数字量输入模块,16路输入,24VDC,1ms,漏式/源式,2个电隔离输入组
7DI645.7 2003系列数字量输入模块,8路输入,100-240VDC,50ms
7DM435.7 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM438.72 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM465.7 2003系列数字量混合模块,16路输入24VDC,1ms,漏式,16路晶体管输出24VDC,0.5A
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7DI135.70 2003系列数字量输入模块,4路输入24VDC,漏式,输入增量式编码器信号: 50 kHz,输入事件计数器信号:  100 kHz,1个比较器信号输出
7DI138.70 2003系列数字量输入模块,10路输入24VDC,漏式,输入2个事件计数器信号,输入频率20kHz
7DI140.70 2003系列数字量输入模块,10路输入24VDC,漏式,输入2个事件计数器信号或者带方向的位置测量
7DO435.7 2003系列数字量输出模块,8路FET输出,24 VDC,2A. 输出端也可设置成输入端
7DO720.7 2003系列数字量输出模块,8路继电器输出,240VAC/30VDC,2A
7DO721.7 2003系列数字量输出模块,4路继电器输出,240VAC/24VDC,4A
7DO722.7 2003系列数字量输出模块,8路继电器输出,240VAC/24VDC,2.5A
7DM435.7 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM438.72 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM465.7 2003系列数字量混合模块,16路输入24VDC,1ms,漏式,16路晶体管输出24VDC,0.5A
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7MM424.70-1 2003系列电机模块,4个电机数字量输出等级,24VDC,3A/50°C,***大启动电流10A (max.50 ms)
7MM432.70-1 2003系列电机跨接模块,2个电机(H)跨接,10-30VDC@4A,峰值电流***高8A(max.2s),集成电流调节器
7DO135.70 2003系列数字量输出模块,4路FET输出,12-24VDC,0.1A,旋入式模块
7DO138.70 2003系列数字量输出模块,8路输出端24VDC,0.5 A,短路保护,热过载保护,旋入式模块
7DO139.70 2003系列数字量输出模块,8路输出端,12-24VDC,0.5A,短路保护,热过载保护,旋入式模块
7DO164 .70 2003系列数字量输出模块,4路FET输出 48-24VDC,0.05A,零交叉测试,旋入式模块
7DM435.7 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM438.72 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM465.7 2003系列数字量混合模块,16路输入24VDC,1ms,漏式,16路晶体管输出24VDC,0.5A
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7AI261.7 2003系列模拟量输入模块,1个全桥附值的输入通道,24-bit,旋入式模块
7AI294.7 2003系列模拟量输入模块,4路输入,电位器测量,13-bit,旋入式模块
7AI351.70 2003系列模拟量输入模块,1个输入,+/10 V或0-20 mA, 12-bit +符号位,旋入式模块
7AI354.70 2003系列模拟量输入模块,4路输入,+/10V,12-bit+符号位,旋入式模块
7AI774.70 2003系列模拟量输入模块,4路输入,0-20 mA,12-bit,旋入式模块
7AM351.70 2003系列模拟量混合模块,1路输入,±10V,16-bit,1路输出,±10V,16-bit,旋入式模块
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7AO352.70 2003系列模拟量输出模块,2个输出,+/10V或0-20mA,12-bit,旋入式模块
7AM351.70 2003系列模拟量混合模块,1路输入,±10V,16-bit,1路输出,±10V,16-bit,旋入式模块
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7AM351.70 2003系列模拟量混合模块,1路输入,±10V,16-bit,1路输出,±10V,16-bit,旋入式模块
7AT324.70 2003系列模拟量输入模块,4路温度输入(2线连接),KTY10-50 - +150°C,KTY84 -40 - +300°C, PT100 -200 - +850°C
7AT352.70 2003系列模拟量输入模块,2路输入,PT100(3线连接技术),-200 - +850°C,旋入式模块
7AT664.70 2003系列模拟量输入模块,4路输入,热电偶,-270 - +1,372°C,旋入式模块
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7MM424.70-1 2003系列电机控制,4个电机数字量输出等级,
24VDC,3A/50°C,***大启动电流10A (max.50 ms)
7MM432.70-1 2003系列电机桥模块,2个电机(H)跨接,
10-30VDC@4A,峰值电流***高8A(max.2s),集成电流调节器
3IF613.9 2005系列接口模块,3个RS232接口,插在CPU和IF模块上
3IF621.9 2005系列接口模块,1个RS485/RS422接口,1个CAN接口,电隔离,可连接网络,插在CPU和IF模块上
3IF622.9 2005系列接口模块,1个RS232接口,2个RS485/RS422接口:  电隔离,可连接网络,插在CPU和IF模块上
3IF661.9 2005系列接口模块,1个RS485接口,电隔离,可连接网络,传输协议: Profibus DP,插在CPU和IF模块上
3IF671.9 2005系列接口模块,1个RS232接口,1个RS485/RS422接口,电隔离,可连接网络,1个CAN接口,电隔离,可连接网络,插在CPU和IF模块上
3IF672.9 2005系列接口模块,1个RS232接口,2个CAN接口: 电隔离,可连接网络,插在CPU和IF模块上
3IF681.86 2005系列接口模块,1个RS232接口,1个Ethernet接口,带10BASE-T双绞线RJ45接头
3IF686.9 2005系列接口模块,1个ETHERNET Powerlink接口,管理器或控制器功能,电隔离
7IF311.7 2003系列接口模块,1个RS232接口,旋入式模块
7IF321.7 2003系列接口模块,1个RS485/RS422接口,电隔离,可连接网络,旋入式模块
7IF361.70-1 2003系列接口模块,1个RS485接口,电隔离,可连接网络,传输协议: Profibus DP,旋入式模块
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7DI135.70 2003系列数字量输入模块,4路输入24VDC,漏式,输入增量式编码器信号: 50 kHz,输入事件计数器信号:  100 kHz,1个比较器信号输出
7DI138.70 2003系列数字量输入模块,10路输入24VDC,漏式,输入2个事件计数器信号,输入频率20kHz
7DI140.70 2003系列数字量输入模块,10路输入24VDC,漏式,输入2个事件计数器信号或者带方向的位置测量
7NC161.7 2003系列编码器模块，输入频率100kHz，增量式或绝对式，32-bit，编码器供电5VDC或24VDC,旋入式模块
7BP702.0 2003系列模块底板可安装2个模块
7BP703.0 2003系列模块底板可安装3个模块
7BP704.0 2003系列模块底板可安装4个模块
7BP705.0 2003系列模块底板可安装5个模块
7BP706.0 2003系列模块底板可安装6个模块
7BP707.0 2003系列模块底板可安装7个模块
7BP708.0 2003系列模块底板可安装8个模块
7BP709.0 2003系列模块底板可安装9个模块
7BP710.0 2003系列模块底板可安装10个模块
7BP701.1 2003系统模块底板可安装1个模块，仅包括右挡板
7BP702.1 2003系统模块底板可安装2个模块，仅包括右挡板
7ME770.5 2003系列配置内存用于CAN总线控制器
3IF786.9贝加莱接口模块
