贝加莱伺服电机

贝加莱伺服电机8KS三相同步电机可以配置各种不同的编码器系统。通常，它们配有Heidenhain EnDat 编码器。根据具体的应用，用户可以选择单圈或多圈光电式编码器。无需寻参过程或者附加测量系统便可运行。8KS三相同步电机也可以配置旋变器以适用于低精度和低速度的机械。

贝加莱伺服电机8LT三相同步电机配有高分辨率的EnDat Heidenhain编码器。还可以选用多圈编码器。无需寻参过程或者附加测量系统便可运行。无电池的绝对式编码器免维护。
贝加莱伺服电机8JS三相同步电机可以配置各种不同的编码器系统。通常，它们配有Heidenhain EnDat 编码器。无电池的绝对式编码器免维护。8JS三相同步电机也可以配置旋变器以适用于低精度和低速度的机械。

贝加莱伺服电机8LSN三相同步电机可以配置各种不同的编码器系统。通常，它们配有Heidenhain EnDat 编码器。根据具体的应用，用户可以选择标准分辨率或者高分辨率编码器。两种分辨率编码器都提供多圈编码器类型。无需寻参过程或者附加测量系统便可运行。无电池的绝对式编码器免维护。8LSN三相同步电机也可以配置旋变器以适用于低精度和低速度的机械。

贝加莱伺服电机8LS三相同步电机可以配置各种不同的编码器系统。通常，它们配有Heidenhain EnDat 编码器。根据具体的应用，用户可以选择标准分辨率或者高分辨率编码器。两种分辨率编码器都提供多圈编码器类型。无需寻参过程或者附加测量系统便可运行。无电池的绝对式编码器免维护。8LS三相同步电机也可以配置旋变器以适用于低精度和低速度的机械。




贝加莱8LVA紧凑型电机特点：
8LV - 紧凑型伺服驱动技术
当在极其狭小的空间内安装伺服电机的时候，贝加莱8LV电机系列 正是您所需要的。8LV电机配有旋变器或先进的EnDat 2.2 接口以满足***高的要求。8LV系列电机转动惯量低，具有很高的动态特性和优异的自加速性 能。这款电机以IP54防护等级作为标准，也可选IP65防护等级。电机可以选用抱闸。8LV电机专为ACOPOSmicro 伺服驱动器而设计，可以提供极高的性能，而且结构极其紧凑。8LV伺服电机的应用范围非常广泛，在1 kW以下功率范围内能够 提供***佳的性价比。
8LV同步电机特殊的表面结构使其适用于食品饮料行业。能够避免遗漏的液体在凹陷处聚集的现象。

特点：
极其紧凑，高动态性能
功率范围可达1 kW，适合80 VDC和320 VDC直流母线电压e
多圈编码器具有相同长度
可靠的EMC屏蔽接头
快速，简单且自动锁定
可选购一体化减速电机

8LV三相同步电机所有相关的机械和电气数据及信息都存储于EnDat编码器中。因此，对于用户来说无需在伺服驱动上做任何设置。当编码器和伺服驱动器相连时，上电后电机将会被自动识别。电机将额定参数和限制参数传送至伺服驱动。驱动自动选择能够控制电机所要用到的***佳电流限制参数和控制参数。用户只要负责优化速度和位置控制参数。贝加莱Automation StudioTM 软件中集成的调试环境为用户提供支持。另外，这还有助于使常规的维护更加简便，电机更换时无需再花时间设置参数。

8LV伺服电机系列是自冷却型（冷却类型A），可用3种不同的尺寸（1，2，3）。在尺寸（特别是法兰尺寸）和额定功率方面提供不同的选择。不同的尺寸通过电机型号中不同的数字（c）来表示。数字越大，电机的法兰尺寸和额定功率也就越大。
8LV系列有2 种不同的长度。相同的法兰尺寸有不同的额定功率。电机型号中的数字（d）表示不同的长度。

根据客户的不同需求，8LV伺服电机可以选择
各种额定速度
有或无油封
有或无抱闸
带光轴或键轴

贝加莱8LVA紧凑型电机尺寸1：
8LVA13.ee015ffgg-0
Synchronous motor, self-cooling, size 1, length 3, speed 1500 rpm
8LVA13.ee030ffgg-0
Synchronous motor, self-cooling, size 1, length 3, speed 3000 rpm

贝加莱8LVA紧凑型电机尺寸2：
8LVA22.ee015ffgg-0
Synchronous motor, self-cooling, size 2, length 2, speed 1500 rpm
8LVA22.ee030ffgg-0
Synchronous motor, self-cooling, size 2, length 2, speed 3000 rpm
8LVA23.ee015ffgg-0
Synchronous motor, self-cooling, size 2, length 3, speed 1500 rpm
8LVA23.ee030ffgg-0
Synchronous motor, self-cooling, size 2, length 3, speed 3000 rpm

贝加莱8LVA紧凑型电机尺寸3：
8LVA33.ee015ffgg-0
Synchronous motor, self-cooling, size 3, length 3, speed 1500 rpm
8LVA33.ee021ffgg-0
Synchronous motor, self-cooling, size 3, length 3, speed 2100 rpm

贝加莱8LVA紧凑型电机附件：
8BPM0004.0000-00
9-pin motor connector, SpringTec, IP67, crimp contact included in delivery: 4 x 0.5-1.5 mm2 + 5 x 0.14-1.0 mm2,...
8BPR0002.0000-00
12-pin encoder connector, SpringTec, IP67, crimp contact included in delivery: 12x 0.14 - 1.0 mm2, 1x keyed contact...

贝加莱伺服电机贝加莱8LVB减速电机特点：
8LVB减速电机
在伺服电机上直接安装减速器可以减少重量，节约空间，并增加运动质量。这些电机配有旋变器或先进的EnDat 2.2 接口以满足***高的要求。8LVB系列电机转动惯量低，具有很高的动态特性和优异的自加速性能。通常，这些组合具有IP54防护等级。它们能够在极小的空间内提供***高性能，是市场上***紧凑的系统。8LVB电机/减速器组合的应用范围非常广泛，在1 kW以下功率范围内能够提供***佳的性价比。
在8GM系列中（M - 在电机上直接安装减速器），可以在标准的8GM40和8GM50减速器系列中进行选择。8GM50系列经过优化以处理更大的径向力和轴向力。标准型减速器是一级减速比i = 3，4，5，8和10，背隙为 <8–15弧分。此外，这些减速器还拥有二级设计，并可选光轴。

贝加莱8LVB减速电机尺寸1：
8LVB13.ee003LjCn00
Motor & gearbox configuration 1185779
8LVB13.ee003LjFn00
Motor & gearbox configuration 1185787
8LVB13.ee003SjFn00
Motor & gearbox configuration 1185611
8LVB13.ee004LjCn00
Motor & gearbox configuration 1185792
8LVB13.ee004LjFn00
Motor & gearbox configuration 1185793
8LVB13.ee004SjCn00
Motor & gearbox configuration 1185612
8LVB13.ee004SjFn00
Motor & gearbox configuration 1185635
8LVB13.ee005LjCn00
Motor & gearbox configuration 1185798
8LVB13.ee005LjFn00
Motor & gearbox configuration 1185802
8LVB13.ee008LjCn00
Motor & gearbox configuration 1185805
8LVB13.ee008LjFn00
Motor & gearbox configuration 1185808
8LVB13.ee008SjCn00
Motor & gearbox configuration 1185639
8LVB13.ee009LjCn00
Motor & gearbox configuration 1185815
8LVB13.ee009LjFn00
Motor & gearbox configuration 1185818
8LVB13.ee009SjFn00
Motor & gearbox configuration 1185689
8LVB13.ee010LjCn00
Motor & gearbox configuration 1181181
8LVB13.ee010LjFn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB13.ee012LjCn00
Motor & gearbox configuration 1185822
8LVB13.ee012LjFn00
Motor & gearbox configuration 1185824
8LVB13.ee012SjFn00
Motor & gearbox configuration 1185694
8LVB13.ee015LjCn00
Motor & gearbox configuration 1185828
8LVB13.ee015LjFn00
Motor & gearbox configuration 1185829
8LVB13.ee015SjCn00
Motor & gearbox configuration 1185704
8LVB13.ee015SjFn00
Motor & gearbox configuration 1185711
8LVB13.ee016LjCn00
Motor & gearbox configuration 1185837
8LVB13.ee016SjCn00
Motor & gearbox configuration 1185717
8LVB13.ee016SjFn00
Motor & gearbox configuration 1185720
8LVB13.ee020LjCn00
Motor & gearbox configuration 1185846
8LVB13.ee020LjFn00
Motor & gearbox configuration 1185850
8LVB13.ee020SjCn00
Motor & gearbox configuration 1185727
8LVB13.ee020SjFn00
Motor & gearbox configuration 1185750
8LVB13.ee025LjCn00
Motor & gearbox configuration 1185853
8LVB13.ee025LjFn00
Motor & gearbox configuration 1185854
8LVB13.ee025SjFn00
Motor & gearbox configuration 1185734
8LVB13.ee032LjCn00
Motor & gearbox configuration 1185859
8LVB13.ee032LjFn00
Motor & gearbox configuration 1185863
8LVB13.ee032SjCn00
Motor & gearbox configuration 1185738
8LVB13.ee032SjFn00
Motor & gearbox configuration 1185737
8LVB13.ee040LjCn00
Motor & gearbox configuration 1185865
8LVB13.ee040LjFn00
Motor & gearbox configuration 1185867
8LVB13.ee040SjCn00
Motor & gearbox configuration 1185747
8LVB13.ee064LjCn00
Motor & gearbox configuration 1185870
8LVB13.ee064LjFn00
Motor & gearbox configuration 1185874
8LVB13.ee064SjCn00
Motor & gearbox configuration 1185761
8LVB13.ee064SjFn00
Motor & gearbox configuration 1185758
8LVB13.ee100LjCn00
Motor & gearbox configuration 1185876
8LVB13.ee100LjFn00
Motor & gearbox configuration 1185878
8LVB13.ee100SjCn00
Motor & gearbox configuration 1185770
8LVB13.ee100SjFn00
Motor & gearbox configuration 1185773

贝加莱伺服电机贝加莱8LVB减速电机尺寸2：
8LVB22.ee003LjCn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB22.ee003LjFn00
Motor & gearbox configuration 1186282 configuration 1186282
8LVB22.ee003SjCn00
Motor & gearbox configuration 1186016
8LVB22.ee004LjCn00
Motor & gearbox configuration 1186286 configuration 1186286
8LVB22.ee004LjFn00
Motor & gearbox configuration 1186296 configuration 1186296
8LVB22.ee004SjCn00
Motor & gearbox configuration 1186021
8LVB22.ee004SjFn00
Motor & gearbox configuration 1186023
8LVB22.ee005LjCn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB22.ee005LjFn00
Motor & gearbox configuration 1186310 configuration 1186310
8LVB22.ee008LjCn00
Motor & gearbox configuration 1186339 configuration 1186339
8LVB22.ee008LjFn00
Motor & gearbox configuration 1186343 configuration 1186343
8LVB22.ee009LjCn00
Motor & gearbox configuration 1186352 configuration 1186352
8LVB22.ee009LjFn00
Motor & gearbox configuration 1186357 configuration 1186357
8LVB22.ee009SjCn00
Motor & gearbox configuration 1186109 configuration 1186109
8LVB22.ee009SjFn00
Motor & gearbox configuration 1186116 configuration 1186116
8LVB22.ee010LjCn00
Motor & gearbox configuration 1186348 configuration 1186348
8LVB22.ee010LjFn00
Motor & gearbox configuration 1186349 configuration 1186349
8LVB22.ee010SjFn00
Motor & gearbox configuration 1186107 configuration 1186107
8LVB22.ee012LjCn00
Motor & gearbox configuration 1186364 configuration 1186364
8LVB22.ee012LjFn00
Motor & gearbox configuration 1186367 configuration 1186367
8LVB22.ee012SjCn00
Motor & gearbox configuration 1186123 configuration 1186123
8LVB22.ee012SjFn00
Motor & gearbox configuration 1186129 configuration 1186129
8LVB22.ee015LjCn00
Motor & gearbox configuration 1186404 configuration 1186404
8LVB22.ee015SjFn00
Motor & gearbox configuration 1186135 configuration 1186135
8LVB22.ee016LjCn00
Motor & gearbox configuration 1186411 configuration 1186411
8LVB22.ee016LjFn00
Motor & gearbox configuration 1186418 configuration 1186418
8LVB22.ee016SjCn00
Motor & gearbox configuration 1186137 configuration 1186137
8LVB22.ee020LjCn00
Motor & gearbox configuration 1186421 configuration 1186421
8LVB22.ee020LjFn00
Motor & gearbox configuration 1186423 configuration 1186423
8LVB22.ee020SjCn00
Motor & gearbox configuration 1186158 configuration 1186158
8LVB22.ee020SjFn00
Motor & gearbox configuration 1186160 configuration 1186160
8LVB22.ee025LjCn00
Motor & gearbox configuration 1186426 configuration 1186426
8LVB22.ee025LjFn00
Motor & gearbox configuration 1186430 configuration 1186430
8LVB22.ee025SjCn00
Motor & gearbox configuration 1186161 configuration 1186161
8LVB22.ee025SjFn00
Motor & gearbox configuration 1186165 configuration 1186165
8LVB22.ee032LjCn00
Motor & gearbox configuration 1186432 configuration 1186432
8LVB22.ee032LjFn00
Motor & gearbox configuration 1186434 configuration 1186434
8LVB22.ee032SjCn00
Motor & gearbox configuration 1186168 configuration 1186168
8LVB22.ee032SjFn00
Motor & gearbox configuration 1186178 configuration 1186178
8LVB22.ee040LjCn00
Motor & gearbox configuration 1186436 configuration 1186436
8LVB22.ee040LjFn00
Motor & gearbox configuration 1186442 configuration 1186442
8LVB22.ee040SjCn00
Motor & gearbox configuration 1186180 configuration 1186180
8LVB22.ee040SjFn00
Motor & gearbox configuration 1186185 configuration 1186185
8LVB22.ee064LjCn00
Motor & gearbox configuration 1186445 configuration 1186445
8LVB22.ee064LjFn00
Motor & gearbox configuration 1186446 configuration 1186446
8LVB22.ee064SjCn00
Motor & gearbox configuration 1186198 configuration 1186198
8LVB22.ee064SjFn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB22.ee100LjCn00
Motor & gearbox configuration 1186447 configuration 1186447
8LVB22.ee100LjFn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB22.ee100SjCn00
Motor & gearbox configuration 1186217 configuration 1186217
8LVB22.ee100SjFn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB23.ee003LjCn00
Motor & gearbox configuration 1186946 configuration 1186946
8LVB23.ee003LjFn00
Motor & gearbox configuration 1187028 configuration 1187028
8LVB23.ee003SjCn00
Motor & gearbox configuration 1186676 configuration 1186676
8LVB23.ee004LjCn00
Motor & gearbox configuration 1187036 configuration 1187036
8LVB23.ee004LjFn00
Motor & gearbox configuration 1187038 configuration 1187038
8LVB23.ee004SjCn00
Motor & gearbox configuration 1186702 configuration 1186702
8LVB23.ee005LjCn00
Motor & gearbox configuration 1187039 configuration 1187039
8LVB23.ee008LjCn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB23.ee008SjCn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB23.ee009LjCn00
Motor & gearbox configuration 1187085 configuration 1187085
8LVB23.ee009LjFn00
Motor & gearbox configuration 1187109 configuration 1187109
8LVB23.ee009SjCn00
Motor & gearbox configuration 1186757 configuration 1186757
8LVB23.ee009SjFn00
Motor & gearbox configuration 1186825 configuration 1186825
8LVB23.ee010LjFn00
Motor & gearbox configuration 1187083 configuration 1187083
8LVB23.ee010SjCn00
Motor & gearbox configuration 1186730 configuration 1186730
8LVB23.ee012LjCn00
Motor & gearbox configuration 1187114 configuration 1187114
8LVB23.ee012LjFn00
Motor & gearbox configuration 1187118 configuration 1187118
8LVB23.ee012SjCn00
Motor & gearbox configuration 1186840 configuration 1186840
8LVB23.ee012SjFn00
Motor & gearbox configuration 1186844 configuration 1186844
8LVB23.ee015LjFn00
Motor & gearbox configuration 1187124 configuration 1187124
8LVB23.ee015SjCn00
Motor & gearbox configuration 1186850 configuration 1186850
8LVB23.ee015SjFn00
Motor & gearbox configuration 1186858 configuration 1186858
8LVB23.ee016LjCn00
Motor & gearbox configuration 1187128 configuration 1187128
8LVB23.ee016LjFn00
Motor & gearbox configuration 1187135 configuration 1187135
8LVB23.ee016SjFn00
Motor & gearbox configuration 1186862 configuration 1186862
8LVB23.ee020LjCn00
Motor & gearbox configuration 1187139 configuration 1187139
8LVB23.ee020LjFn00
Motor & gearbox configuration 1187145 configuration 1187145
8LVB23.ee020SjCn00
Motor & gearbox configuration 1186863 configuration 1186863
8LVB23.ee020SjFn00
Motor & gearbox configuration 1186870 configuration 1186870
8LVB23.ee025LjCn00
Motor & gearbox configuration 1187151 configuration 1187151
8LVB23.ee025LjFn00
Motor & gearbox configuration 1187165 configuration 1187165
8LVB23.ee025SjCn00
Motor & gearbox configuration 1186872 configuration 1186872
8LVB23.ee025SjFn00
Motor & gearbox configuration 1186895 configuration 1186895
8LVB23.ee032LjCn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB23.ee032LjFn00
Motor & gearbox configuration 1187176 configuration 1187176
8LVB23.ee040LjCn00
Motor & gearbox configuration 1187181 configuration 1187181
8LVB23.ee040LjFn00
Motor & gearbox configuration 1187187 configuration 1187187
8LVB23.ee040SjCn00
Motor & gearbox configuration 1186914 configuration 1186914
8LVB23.ee040SjFn00
Motor & gearbox configuration 1186917 configuration 1186917
8LVB23.ee064LjCn00
Motor & gearbox configuration 1187190 configuration 1187190
8LVB23.ee064LjFn00
Motor & gearbox configuration 1187194 configuration 1187194
8LVB23.ee100LjCn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB23.ee100LjFn00
Motor & gearbox configuration 1187207 configuration 1187207
8LVB23.ee100SjCn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB23.ee100SjFn00
Motor & gearbox configuration 1186936 configuration 1186936

贝加莱伺服电机贝加莱8LVB减速电机尺寸3：
8LVB33.ee003LjCn00
Motor & gearbox configuration 1187138 configuration 1187138
8LVB33.ee003LjDn00
Motor & gearbox configuration 1187142 configuration 1187142
8LVB33.ee003SjCn00
Motor & gearbox configuration 1187302 configuration 1187302
8LVB33.ee003SjDn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB33.ee004LjCn00
Motor & gearbox configuration 1187146 configuration 1187146
8LVB33.ee004LjDn00
Motor & gearbox configuration 1187147 configuration 1187147
8LVB33.ee004SjCn00
Motor & gearbox configuration 1187304 configuration 1187304
8LVB33.ee004SjDn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB33.ee005LjCn00
Motor & gearbox configuration 1187154 configuration 1187154
8LVB33.ee005LjDn00
Motor & gearbox configuration 1187155 configuration 1187155
8LVB33.ee005SjCn00
Motor & gearbox configuration 1187310 configuration 1187310
8LVB33.ee008LjCn00
Motor & gearbox configuration 1187160 configuration 1187160
8LVB33.ee008LjDn00
Motor & gearbox configuration 1187163 configuration 1187163
8LVB33.ee008SjCn00
Motor & gearbox configuration 1187318 configuration 1187318
8LVB33.ee008SjDn00
Motor & gearbox configuration 1187321 configuration 1187321
8LVB33.ee009LjCn00
Motor & gearbox configuration 1187174 configuration 1187174
8LVB33.ee009LjDn00
Motor & gearbox configuration 1187177 configuration 1187177
8LVB33.ee009SjCn00
Motor & gearbox configuration 1187086 configuration 1187086
8LVB33.ee009SjDn00
Motor & gearbox configuration 1187089 configuration 1187089
8LVB33.ee010LjDn00
Motor & gearbox configuration 1187170 configuration 1187170
8LVB33.ee010SjDn00
Motor & gearbox configuration 1187081 configuration 1187081
8LVB33.ee012LjCn00
Motor & gearbox configuration 1187182 configuration 1187182
8LVB33.ee012LjDn00
Motor & gearbox configuration 1187185 configuration 1187185
8LVB33.ee012SjCn00
Motor & gearbox configuration 1187093 configuration 1187093
8LVB33.ee012SjDn00
Motor & gearbox configuration 1187096 configuration 1187096
8LVB33.ee015LjCn00
Motor & gearbox configuration 1187188 configuration 1187188
8LVB33.ee015LjDn00
Motor & gearbox configuration 1187191 configuration 1187191
8LVB33.ee015SjCn00
Motor & gearbox configuration 1187098 configuration 1187098
8LVB33.ee015SjDn00
Motor & gearbox configuration 1187101 configuration 1187101
8LVB33.ee016LjCn00
Motor & gearbox configuration 1187195 configuration 1187195
8LVB33.ee016LjDn00
Motor & gearbox configuration 1187322 configuration 1187322
8LVB33.ee016SjDn00
Motor & gearbox configuration 1187106 configuration 1187106
8LVB33.ee020LjCn00
Motor & gearbox configuration 1187326 configuration 1187326
8LVB33.ee020LjDn00
Motor & gearbox configuration 1187327 configuration 1187327
8LVB33.ee020SjCn00
Motor & gearbox configuration 1187110 configuration 1187110
8LVB33.ee020SjDn00
Motor & gearbox configuration 1187111 configuration 1187111
8LVB33.ee025LjCn00
Motor & gearbox configuration 1187329 configuration 1187329
8LVB33.ee025LjDn00
B1 2.2 Bat ind. 16-line multi-turn without oil seal; DC bus voltage = 80 VDC; brake holding torque: 0.00 Nm angled (swivel); B (self-cooling, construction type B); IP54 protection...
8LVB33.ee025SjDn00
Motor & gearbox configuration 1187116 configuration 1187116
8LVB33.ee032LjCn00
Motor & gearbox configuration 1187333 configuration 1187333
8LVB33.ee032LjDn00
Motor & gearbox configuration 1187335 configuration 1187335
8LVB33.ee032SjCn00
Motor & gearbox configuration 1187120 configuration 1187120
8LVB33.ee032SjDn00
Motor & gearbox configuration 1187123 configuration 1187123
8LVB33.ee040SjDn00
Motor & gearbox configuration 1187126 configuration 1187126
8LVB33.ee064LjCn00
Motor & gearbox configuration 1187342 configuration 1187342
8LVB33.ee064LjDn00
Motor & gearbox configuration 1187346 configuration 1187346
8LVB33.ee064SjCn00
Motor & gearbox configuration 1187129 configuration 1187129
8LVB33.ee064SjDn00
Motor & gearbox configuration 1187133 configuration 1187133
8LVB33.ee100LjCn00
Motor & gearbox configuration 1187349 configuration 1187349
8LVB33.ee100LjDn00
Motor & gearbox configuration 1187352 configuration 1187352
8LVB33.ee100SjDn00
Motor & gearbox configuration 1187136 configuration 1187136

贝加莱8LS同步电机特点：
8LS三相同步电机
8LS系列三相同步电机是专为需要高动态特性和定位精度以及紧凑型结构应用而开发的的永磁电子换向同步电机。

NdFeB永磁体
正弦EnDat编码器或旋变器作为反馈单元
现在可用功能安全编码器
三相星型连接
尺寸紧凑，重量轻巧
良好的转子构造，使转动惯量***小化，保证了优异的动态特性
高负载能力/峰值扭矩
扭矩脉动低
高速时的高动态扭矩
寿命长，除轴承外所有电机部件免磨损
定子产生的功耗通过外壳直接转移到法兰上
预紧的深沟球轴承两端密封并油脂润滑
完整的电机产品线，堵转扭矩范围从0.2 Nm至115 Nm
采用两个SpeedTEC圆形插头进行电气连接
由ACOPOS伺服驱动器或ACOPOSmulti驱动系统控制

8LS三相同步电机不能直接与电源连接，它们只能与ACOPOS伺服驱动器或ACOPOSmulti驱动系统组合起来进行工作！

贝加莱伺服电机贝加莱8LS同步电机首选伺服电机类型：
8LSA25.D8060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 40 mm; j6 A fit...
8LSA25.D8060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.800 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 40 mm; j6 A fit...
8LSA25.D9060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 40 mm; j6 A fit...
8LSA25.D9060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 40 mm; j6 fit...
8LSA25.R0060D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 40 mm; j6 A fit...
8LSA25.R0060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 40 mm; j6 A fit...
8LSA25.R0060D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 40 mm; j6 A fit...
8LSA25.R0060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.800 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 40 mm; j6 A fit...
8LSA35.DA030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm;...
8LSA35.DA030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DA060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DA060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DB030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DB030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DB060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DB060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.EA030D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA030D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA060D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA060D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB030D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB030D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB060D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB060D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.R2030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; without holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.R2030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.R2060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.R2060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA37.DA030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DA030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DA060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DA060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DB030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DB030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DB060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DB060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.R2030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA37.R2030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA37.R2060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA37.R2060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA44.DA030S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA44.DA060S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA44.DA060S200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA44.DB030S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA44.DB030S200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA44.DB060S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA44.DB060S200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA44.EA030D000-0
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EA030D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EA030D200-0
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EA030D200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EA060D000-0
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EA060D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EA060D200-0
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EA060D200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EB030D000-0
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EB030D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EB030D200-0
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EB030D200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EB060D000-0
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EB060D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EB060D200-0
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.EB060D200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.R2030D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.R2030D200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.R2060D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA44.R2060D200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA46.DA030S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 10.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA46.DA030S200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 10.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA46.DA060S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 10.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA46.DA060S200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 10.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA46.DB030S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 10.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA46.DB030S200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 10.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA46.DB060S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 10.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA46.DB060S200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 10.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA46.R2030D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 10.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA46.R2030D200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 10.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA46.R2060D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 10.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA46.R2060D200-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 10.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 95 mm; j6 A fit...
8LSA55.DA030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 130 mm; j6 A fit...
8LSA55.DA030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 130 mm; j6 A fit...
8LSA55.DB030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 130 mm; j6 A fit...
8LSA55.DB030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 130 mm; j6 A fit...
8LSA55.EA030D000-1
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.EA030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.EA030D200-1
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.EA030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.EB030D000-1
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.EB030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.EB030D200-1
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.EB030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.R2030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA55.R2030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 12.500 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA57.DA030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 20.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 130 mm; j6 A fit...
8LSA57.DA030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 20.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 130 mm; j6 A fit...
8LSA57.DB030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 20.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 130 mm; j6 A fit...
8LSA57.DB030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 20.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 130 mm; j6 A fit...
8LSA57.R2030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 20.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA57.R2030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 20.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 130 mm; j6 A fit...
8LSA73.DA030S000-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 26.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 180 mm; j6 A fit...
8LSA73.DA030S200-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 26.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 180 mm; j6 A fit...
8LSA73.DB030S000-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 26.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 180 mm; j6 A fit...
8LSA73.DB030S200-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 26.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 180 mm; j6 A fit...
8LSA73.R2030D000-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 26.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 180 mm; j6 A fit...
8LSA73.R2030D200-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 26.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 180 mm; j6 A fit...
8LSA75.DA030S000-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 40.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 180 mm; j6 A fit...
8LSA75.DA030S200-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 40.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 180 mm; j6 A fit...
8LSA75.DB030S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 40.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 180 mm; j6 A fit...
8LSA75.DB030S200-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 40.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 180 mm; j6 A fit...
8LSA75.R2030D000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 43.000 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 180 mm; j6 fit...
8LSA75.R2030D200-3
Synchronous motor; number of pole pairs: 3 pairs; nominal speed: 3000 rpm stall torque: 40.000 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 180 mm; j6 A fit...

贝加莱8LS同步电机冷却类型A;
贝加莱伺服电机贝加莱8LS同步电机冷却类型A尺寸2:
8LSA23.ee060ffgg-3
S4 6000 0,17 00000 x xx 0 S0 xx S 560 R0
8LSA24.ee060ffgg-3
S4 6000 0,35 00000 x xx 0 S0 xx S 560 R0
8LSA25.ee045ffgg-3
S4 4500 0,54 00000 x xx 0 S0 xx S 560 R0
8LSA25.ee060ffgg-3
S4 6000 0,52 00000 x xx 0 S0 xx S 560 R0
8LSA26.ee045ffgg-3
S4 4500 0,72 00000 x xx 0 S0 xx S 560 R0
8LSA26.ee060ffgg-3
S4 6000 0,69 00000 x xx 0 S0 xx S 560 R0

贝加莱8LS同步电机冷却类型A尺寸3:
8LSA33.ee030ffgg-3
S4 3000 0,7 00000 x xx 0 S0 xx S 560 R2
8LSA33.ee045ffgg-3
S4 4500 0,67 00000 x xx 0 S0 xx S 560 R2
8LSA33.ee060ffgg-3
S4 6000 0,6 00000 x xx 0 S0 xx S 560 R2
8LSA34.ee022ffgg-3
S4 2200 1,4 00000 x xx 0 S0 xx S 560 R2
8LSA34.ee030ffgg-3
S4 3000 1,4 00000 x xx 0 S0 xx S 560 R2
8LSA34.ee045ffgg-3
S4 4500 1,3 00000 x xx 0 S0 xx S 560 R2
8LSA34.ee060ffgg-3
S4 6000 1 00000 x xx 0 S0 xx S 560 R2
8LSA35.ee022ffgg-3
S4 2200 2,1 00000 x xx 0 S0 xx S 560 R2
8LSA35.ee030ffgg-3
S4 3000 2,1 00000 x xx 0 S0 xx S 560 R2
8LSA35.ee045ffgg-3
S4 4500 1,8 00000 x xx 0 S0 xx S 560 R2
8LSA35.ee060ffgg-3
S4 6000 1,6 00000 x xx 0 S0 xx S 560 R2
8LSA36.ee022ffgg-3
S4 2200 2,7 00000 x xx 0 S0 xx S 560 R2
8LSA36.ee030ffgg-3
S4 3000 2,7 00000 x xx 0 S0 xx S 560 R2
8LSA36.ee045ffgg-3
S4 4500 2,2 00000 x xx 0 S0 xx S 560 R2
8LSA36.ee060ffgg-3
S4 6000 1,8 00000 x xx 0 S0 xx S 560 R2
8LSA37.ee030ffgg-3
S4 3000 3,4 00000 x xx 0 S0 xx S 560 R2
8LSA37.ee060ffgg-3
S4 6000 2 00000 x xx 0 S0 xx S 560 R2

贝加莱伺服电机贝加莱8LS同步电机冷却类型A尺寸4:
8LSA43.ee022ffgg-0
Synchronous motor, self-cooling, size 4, length 3, speed 2200 rpm
8LSA43.ee030ffgg-0
Synchronous motor, self-cooling, size 4, length 3, speed 3000 rpm
8LSA43.ee030ffgg-3
S5 3000 3,1 00000 x xx 0 S0 xx S 560 R2
8LSA43.ee045ffgg-0
Synchronous motor, self-cooling, size 4, length 3, speed 4500 rpm
8LSA43.ee045ffgg-3
S5 4500 2,7 00000 x xx 0 S0 xx S 560 R2
8LSA43.ee060ffgg-0
Synchronous motor, self-cooling, size 4, length 3, speed 6000 rpm
8LSA43.ee060ffgg-3
S5 6000 2 00000 x xx 0 S0 xx S 560 R2
8LSA44.ee022ffgg-0
Synchronous motor, self-cooling, size 4, length 4, speed 2200 rpm
8LSA44.ee022ffgg-3
S5 2200 5,2 00000 x xx 0 S0 xx S 560 R2
8LSA44.ee030ffgg-0
Synchronous motor, self-cooling, size 4, length 4, speed 3000 rpm
8LSA44.ee030ffgg-3
S5 3000 4,62 00000 x xx 0 S0 xx S 560 R2
8LSA44.ee045ffgg-0
Synchronous motor, self-cooling, size 4, length 4, speed 4500 rpm
8LSA44.ee045ffgg-3
S5 4500 3,6 00000 x xx 0 S0 xx S 560 R2
8LSA44.ee060ffgg-0
Synchronous motor, self-cooling, size 4, length 4, speed 6000 rpm
8LSA44.ee060ffgg-3
S5 6000 3 00000 x xx 0 S0 xx S 560 R2
8LSA45.ee022ffgg-0
Synchronous motor, self-cooling, size 4, length 5, speed 2200 rpm
8LSA45.ee022ffgg-3
S5 2200 7 00000 x xx 0 S0 xx S 560 R2
8LSA45.ee030ffgg-0
Synchronous motor, self-cooling, size 4, length 5, speed 3000 rpm
8LSA45.ee030ffgg-3
S5 3000 6,16 00000 x xx 0 S0 xx S 560 R2
8LSA45.ee045ffgg-0
Synchronous motor, self-cooling, size 4, length 5, speed 4500 rpm
8LSA45.ee045ffgg-3
S5 4500 4,8 00000 x xx 0 S0 xx S 560 R2
8LSA45.ee060ffgg-0
Synchronous motor, self-cooling, size 4, length 5, speed 6000 rpm
8LSA45.ee060ffgg-3
S5 6000 4 00000 x xx 0 S0 xx S 560 R2
8LSA46.ee022ffgg-0
Synchronous motor, self-cooling, size 4, length 6, speed 2200 rpm
8LSA46.ee022ffgg-3
S5 2200 8,7 00000 x xx 0 S0 xx S 560 R2
8LSA46.ee030ffgg-0
Synchronous motor, self-cooling, size 4, length 6, speed 3000 rpm
8LSA46.ee030ffgg-3
S5 3000 7,7 00000 x xx 0 S0 xx S 560 R2
8LSA46.ee045ffgg-0
Synchronous motor, self-cooling, size 4, length 6, speed 4500 rpm
8LSA46.ee045ffgg-3
S5 4500 6 00000 x xx 0 S0 xx S 560 R2
8LSA46.ee060ffgg-0
Synchronous motor, self-cooling, size 4, length 6, speed 6000 rpm
8LSA46.ee060ffgg-3
S5 6000 5 00000 x xx 0 S0 xx S 560 R2

贝加莱伺服电机贝加莱8LS同步电机冷却类型A尺寸5:
8LSA53.ee022ffgg-1
Synchronous motor, self-cooling, size 5, length 3, speed 2200 rpm
8LSA53.ee030ffgg-1
Synchronous motor, self-cooling, size 5, length 3, speed 3000 rpm
8LSA53.ee030ffgg-3
S4 3000 4 00000 x xx 0 S0 xx S 560 R0
8LSA53.ee045ffgg-1
Synchronous motor, self-cooling, size 5, length 3, speed 4500 rpm
8LSA53.ee045ffgg-3
S4 4500 3,9 00000 x xx 0 S0 xx S 560 R0
8LSA54.ee022ffgg-1
Synchronous motor, self-cooling, size 5, length 4, speed 2200 rpm
8LSA54.ee022ffgg-3
S4 2200 7,8 00000 x xx 0 S0 xx S 560 R0
8LSA54.ee030ffgg-1
Synchronous motor, self-cooling, size 5, length 4, speed 3000 rpm
8LSA54.ee030ffgg-3
S4 3000 7,7 00000 x xx 0 S0 xx S 560 R0
8LSA54.ee045ffgg-1
Synchronous motor, self-cooling, size 5, length 4, speed 4500 rpm
8LSA54.ee045ffgg-3
S4 4500 7,3 00000 x xx 0 S0 xx S 560 R0
8LSA55.ee022ffgg-1
Synchronous motor, self-cooling, size 5, length 5, speed 2200 rpm
8LSA55.ee022ffgg-3
S4 2200 11,8 00000 x xx 0 S0 xx S 560 R0
8LSA55.ee030ffgg-1
Synchronous motor, self-cooling, size 5, length 5, speed 3000 rpm
8LSA55.ee030ffgg-3
S4 3000 11,6 00000 x xx 0 S0 xx S 560 R0
8LSA55.ee045ffgg-1
Synchronous motor, self-cooling, size 5, length 5, speed 4500 rpm
8LSA55.ee045ffgg-3
S4 4500 9,5 00000 x xx 0 S0 xx S 560 R0
8LSA56.ee022ffgg-1
Synchronous motor, self-cooling, size 5, length 6, speed 2200 rpm
8LSA56.ee022ffgg-3
S4 2200 14,4 00000 x xx 0 S0 xx S 560 R0
8LSA56.ee030ffgg-1
Synchronous motor, self-cooling, size 5, length 6, speed 3000 rpm
8LSA56.ee030ffgg-3
S4 3000 13,9 00000 x xx 0 S0 xx S 560 R0
8LSA56.ee045ffgg-1
Synchronous motor, self-cooling, size 5, length 6, speed 4500 rpm
8LSA56.ee045ffgg-3
S4 4500 12,7 00000 x xx 0 S0 xx S 560 R0
8LSA57.ee022ffgg-1
Synchronous motor, self-cooling, size 5, length 7, speed 2200 rpm
8LSA57.ee022ffgg-3
S4 2200 18 00000 x xx 0 S0 xx S 560 R0
8LSA57.ee030ffgg-1
Synchronous motor, self-cooling, size 5, length 7, speed 3000 rpm
8LSA57.ee030ffgg-3
S4 3000 17,5 00000 x xx 0 S0 xx S 560 R0
8LSA57.ee045ffgg-1
Synchronous motor, self-cooling, size 5, length 7, speed 4500 rpm
8LSA57.ee045ffgg-3
S4 4500 15 00000 x xx 0 S0 xx S 560 R0

贝加莱伺服电机贝加莱8LS同步电机冷却类型A尺寸6:
8LSA63.ee022ffgg-1
Synchronous motor, self-cooling, size 6, length 3, speed 2200 rpm
8LSA63.ee030ffgg-1
Synchronous motor, self-cooling, size 6, length 3, speed 3000 rpm
8LSA63.ee030ffgg-3
S4 3000 11,6 00000 x xx 0 S0 xx S 560 R0
8LSA63.ee045ffgg-1
Synchronous motor, self-cooling, size 6, length 3, speed 4500 rpm
8LSA63.ee045ffgg-3
S4 4500 9,5 00000 x xx 0 S0 xx S 560 R0
8LSA64.ee022ffgg-1
Synchronous motor, self-cooling, size 6, length 4, speed 2200 rpm
8LSA64.ee022ffgg-3
S4 2200 18 00000 x xx 0 S0 xx S 560 R0
8LSA64.ee030ffgg-1
Synchronous motor, self-cooling, size 6, length 4, speed 3000 rpm
8LSA64.ee030ffgg-3
S4 3000 17,5 00000 x xx 0 S0 xx S 560 R0
8LSA64.ee045ffgg-1
Synchronous motor, self-cooling, size 6, length 4, speed 4500 rpm
8LSA64.ee045ffgg-3
S4 4500 15,1 00000 x xx 0 S0 xx S 560 R0
8LSA65.ee022ffgg-1
Synchronous motor, self-cooling, size 6, length 5, speed 2200 rpm
8LSA65.ee022ffgg-3
S4 2200 22 00000 x xx 0 S0 xx S 560 R0
8LSA65.ee030ffgg-1
Synchronous motor, self-cooling, size 6, length 5, speed 3000 rpm
8LSA65.ee030ffgg-3
S4 3000 21 00000 x xx 0 S0 xx S 560 R0
8LSA65.ee045ffgg-1
Synchronous motor, self-cooling, size 6, length 5, speed 4500 rpm
8LSA65.ee045ffgg-3
S4 4500 12,2 00000 x xx 0 S0 xx S 560 R0
8LSA66.ee022ffgg-1
Synchronous motor, self-cooling, size 6, length 6, speed 2200 rpm
8LSA66.ee022ffgg-3
S4 2200 24,5 00000 x xx 0 S0 xx S 560 R0
8LSA66.ee030ffgg-1
Synchronous motor, self-cooling, size 6, length 6, speed 3000 rpm
8LSA66.ee030ffgg-3
S4 3000 23,5 00000 x xx 0 S0 xx S 560 R0
8LSA66.ee045ffgg-1
Synchronous motor, self-cooling, size 6, length 6, speed 4500 rpm
8LSA66.ee045ffgg-3
S4 4500 15 00000 x xx 0 S0 xx S 560 R0

贝加莱8LS同步电机冷却类型A尺寸7:
8LSA73.ee022ffgg-3
S5 2200 21.9 00000 x xx 0 S0 xx S 560 R0
8LSA73.ee030ffgg-3
S5 3000 20.5 00000 x xx 0 S0 xx S 560 R0
8LSA73.ee045ffgg-3
S5 4500 16 00000 x xx 0 S0 xx S 560 R0
8LSA74.ee022ffgg-3
S5 2200 27.5 00000 x xx 0 S0 xx S 560 R0
8LSA74.ee030ffgg-3
S5 3000 25 00000 x xx 0 S0 xx S 560 R0
8LSA74.ee045ffgg-3
S5 4500 18 00000 x xx 0 S0 xx S 560 R0
8LSA75.ee022ffgg-3
S5 2200 34 00000 x xx 0 S0 xx S 560 R0
8LSA75.ee030ffgg-3
S5 3000 30 00000 x xx 0 S0 xx S 560 R0
8LSA76.ee015ffgg-3
S5 1500 48,5 00000 x xx 0 S0 xx S 560 R0
8LSA76.ee030ffgg-3
S5 3000 35 00000 x xx 0 S0 xx S 560 R0
8LSA77.ee030ffgg-3
S5 3000 40 00000 x xx 0 S0 xx S 560 R0
8LSA78.ee030ffgg-3
S5 3000 44 00000 x xx 0 S0 xx S 560 R0

贝加莱伺服电机贝加莱8LS同步电机冷却类型A尺寸8:
8LSA83.ee022ffgg-0
S3 2200 31 00000 x xx 0 S0 xx S 560 R2
8LSA84.ee022ffgg-0
S6 2200 51,5 00000 x xx 0 S0 xx S 560 R0
8LSA84.ee030ffgg-0
S6 3000 48,4 00000 x xx 0 S0 xx S 560 R0
8LSA85.ee020ffgg-0
S6 2000 72 00000 x xx 0 S0 xx S 560 R0
8LSA86.ee015ffgg-0
S6 1500 97 00000 x xx 0 S0 xx S 560 R0
8LSA86.ee020ffgg-0
S6 2000 85 00000 x xx 0 S0 xx S 560 R0

贝加莱伺服电机贝加莱8LS同步电机冷却类型C；
贝加莱8LS同步电机冷却类型C尺寸4：
8LSC43.ee022ffgg-1
Synchronous motor, external cooling, size 4, length 3, rated speed 2200 rpm
8LSC43.ee022ffgg-3
S5 2200 4.55 00000 x xx 0 F0 xx S 560 R0
8LSC43.ee030ffgg-1
Synchronous motor, external cooling, size 4, length 3, rated speed 3000 rpm
8LSC43.ee030ffgg-3
S5 3000 4.03 00000 x xx 0 F0 xx S 560 R0
8LSC43.ee045ffgg-1
Synchronous motor, external cooling, size 4, length 3, rated speed 4500 rpm
8LSC43.ee045ffgg-3
S5 4500 3.51 00000 x xx 0 F0 xx S 560 R0
8LSC43.ee060ffgg-1
Synchronous motor, external cooling, size 4, length 3, rated speed 6000 rpm
8LSC43.ee060ffgg-3
S5 6000 2.6 00000 x xx 0 F0 xx S 560 R0
8LSC44.ee022ffgg-1
Synchronous motor, external cooling, size 4, length 4, rated speed 2200 rpm
8LSC44.ee022ffgg-3
S5 2200 6.76 00000 x xx 0 F0 xx S 560 R0
8LSC44.ee030ffgg-1
Synchronous motor, external cooling, size 4, length 4, rated speed 3000 rpm
8LSC44.ee030ffgg-3
S5 3000 6.01 00000 x xx 0 F0 xx S 560 R0
8LSC44.ee045ffgg-1
Synchronous motor, external cooling, size 4, length 4, rated speed 4500 rpm
8LSC44.ee045ffgg-3
S5 4500 4.68 00000 x xx 0 F0 xx S 560 R0
8LSC44.ee060ffgg-1
Synchronous motor, external cooling, size 4, length 4, rated speed 6000 rpm
8LSC44.ee060ffgg-3
S5 6000 3.9 00000 x xx 0 F0 xx S 560 R0
8LSC45.ee022ffgg-1
Synchronous motor, external cooling, size 4, length 5, rated speed 2200 rpm
8LSC45.ee022ffgg-3
S5 2200 9.1 00000 x xx 0 F0 xx S 560 R0
8LSC45.ee030ffgg-1
Synchronous motor, external cooling, size 4, length 5, rated speed 3000 rpm
8LSC45.ee030ffgg-3
S5 3000 8.01 00000 x xx 0 F0 xx S 560 R0
8LSC45.ee045ffgg-1
Synchronous motor, external cooling, size 4, length 5, rated speed 4500 rpm
8LSC45.ee045ffgg-3
S5 4500 6.24 00000 x xx 0 F0 xx S 560 R0
8LSC45.ee060ffgg-1
Synchronous motor, external cooling, size 4, length 5, rated speed 6000 rpm
8LSC45.ee060ffgg-3
S5 6000 5.2 00000 x xx 0 F0 xx S 560 R0
8LSC46.ee022ffgg-1
Synchronous motor, external cooling, size 4, length 6, rated speed 2200 rpm
8LSC46.ee022ffgg-3
S5 2200 11,31 00000 x xx 0 F0 xx S 560 R
8LSC46.ee030ffgg-1
Synchronous motor, external cooling, size 4, length 6, rated speed 3000 rpm
8LSC46.ee030ffgg-3
S5 3000 10,01 00000 x xx 0 F0 xx S 560 R
8LSC46.ee045ffgg-1
Synchronous motor, external cooling, size 4, length 6, rated speed 4500 rpm
8LSC46.ee045ffgg-3
S5 4500 7.8 00000 x xx 0 F0 xx S 560 R0
8LSC46.ee060ffgg-1
Synchronous motor, external cooling, size 4, length 6, rated speed 6000 rpm
8LSC46.ee060ffgg-3
S5 6000 6.5 00000 x xx 0 F0 xx S 560 R0

贝加莱伺服电机贝加莱8LS同步电机冷却类型C尺寸5：
8LSC53.ee022ffgg-2
Synchronous motor, external cooling, size 5, length 3, rated speed 2200 rpm
8LSC53.ee022ffgg-3
S4 2200 5,46 00000 x xx 0 F0 xx S 560 R0
8LSC53.ee030ffgg-2
Synchronous motor, external cooling, size 5, length 3, rated speed 3000 rpm
8LSC53.ee030ffgg-3
S4 3000 5,2 00000 x xx 0 F0 xx S 560 R0
8LSC53.ee045ffgg-2
Synchronous motor, external cooling, size 5, length 3, rated speed 4500 rpm
8LSC53.ee045ffgg-3
S4 4500 5,07 00000 x xx 0 F0 xx S 560 R0
8LSC54.ee011ffgg-2
Synchronous motor, external cooling, size 5, length 4, rated speed 1100 rpm
8LSC54.ee011ffgg-3
S4 1100 10,92 00000 x xx 0 F0 xx S 560 R
8LSC54.ee022ffgg-2
Synchronous motor, external cooling, size 5, length 4, rated speed 2200 rpm
8LSC54.ee022ffgg-3
S4 2200 10,14 00000 x xx 0 F0 xx S 560 R
8LSC54.ee030ffgg-2
Synchronous motor, external cooling, size 5, length 4, rated speed 3000 rpm
8LSC54.ee030ffgg-3
S4 3000 10,01 00000 x xx 0 F0 xx S 560 R
8LSC54.ee045ffgg-2
Synchronous motor, external cooling, size 5, length 4, rated speed 4500 rpm
8LSC54.ee045ffgg-3
S4 4500 9,49 00000 x xx 0 F0 xx S 560 R0
8LSC55.ee022ffgg-2
Synchronous motor, external cooling, size 5, length 5, rated speed 2200 rpm
8LSC55.ee022ffgg-3
S4 2200 15,34 00000 x xx 0 F0 xx S 560 R
8LSC55.ee030ffgg-2
Synchronous motor, external cooling, size 5, length 5, rated speed 3000 rpm
8LSC55.ee030ffgg-3
S4 3000 15,08 00000 x xx 0 F0 xx S 560 R
8LSC55.ee045ffgg-2
Synchronous motor, external cooling, size 5, length 5, rated speed 4500 rpm
8LSC55.ee045ffgg-3
S4 4500 12,35 00000 x xx 0 F0 xx S 560 R
8LSC56.ee022ffgg-2
Synchronous motor, external cooling, size 5, length 6, rated speed 2200 rpm
8LSC56.ee022ffgg-3
S4 2200 18,72 00000 x xx 0 F0 xx S 560 R
8LSC56.ee030ffgg-2
Synchronous motor, external cooling, size 5, length 6, rated speed 3000 rpm
8LSC56.ee030ffgg-3
S4 3000 18,07 00000 x xx 0 F0 xx S 560 R
8LSC56.ee045ffgg-2
Synchronous motor, external cooling, size 5, length 6, rated speed 4500 rpm
8LSC56.ee045ffgg-3
S4 4500 16,51 00000 x xx 0 F0 xx S 560 R
8LSC57.ee022ffgg-2
Synchronous motor, external cooling, size 5, length 7, rated speed 2200 rpm
8LSC57.ee022ffgg-3
S4 2200 23,4 00000 x xx 0 F0 xx S 560 R0
8LSC57.ee030ffgg-2
Synchronous motor, external cooling, size 5, length 7, rated speed 3000 rpm
8LSC57.ee030ffgg-3
S4 3000 22,75 00000 x xx 0 F0 xx S 560 R
8LSC57.ee045ffgg-2
Synchronous motor, external cooling, size 5, length 7, rated speed 4500 rpm
8LSC57.ee045ffgg-3
S4 4500 19,5 00000 x xx 0 F0 xx S 560 R0
8LSC5A.ee022ffgg-0
Synchronous motor, external cooling, size 5, length A, rated speed 2200 rpm
8LSC5A.ee030ffgg-0
Synchronous motor, external cooling, size 5, length A, rated speed 3000 rpm
8LSC5A.ee045ffgg-0
Synchronous motor, external cooling, size 5, length A, rated speed 4500 rpm
8LSC5B.ee022ffgg-0
Synchronous motor, external cooling, size 5, length B, rated speed 2200 rpm
8LSC5B.ee030ffgg-0
Synchronous motor, external cooling, size 5, length B, rated speed 3000 rpm
8LSC5B.ee045ffgg-0
Synchronous motor, external cooling, size 5, length B, rated speed 4500 rpm
8LSC5C.ee022ffgg-0
Synchronous motor, external cooling, size 5, length C, rated speed 2200 rpm
8LSC5C.ee030ffgg-0
Synchronous motor, external cooling, size 5, length C, rated speed 3000 rpm
8LSC5C.ee045ffgg-0
Synchronous motor, external cooling, size 5, length C, rated speed 4500 rpm

贝加莱伺服电机贝加莱8LS同步电机冷却类型C尺寸6：
8LSC63.ee022ffgg-2
Synchronous motor, external cooling, size 6, length 3, rated speed 2200 rpm
8LSC63.ee022ffgg-3
S4 2200 15,34 00000 x xx 0 F0 xx S 560 R
8LSC63.ee030ffgg-2
Synchronous motor, external cooling, size 6, length 3, rated speed 3000 rpm
8LSC63.ee030ffgg-3
S4 3000 15,08 00000 x xx 0 F0 xx S 560 R
8LSC63.ee045ffgg-2
Synchronous motor, external cooling, size 6, length 3, rated speed 4500 rpm
8LSC63.ee045ffgg-3
S4 4500 12,35 00000 x xx 0 F0 xx S 560 R
8LSC64.ee022ffgg-2
Synchronous motor, external cooling, size 6, length 4, rated speed 2200 rpm
8LSC64.ee022ffgg-3
S4 2200 23,4 00000 x xx 0 F0 xx S 560 R0
8LSC64.ee030ffgg-2
Synchronous motor, external cooling, size 6, length 4, rated speed 3000 rpm
8LSC64.ee030ffgg-3
S4 3000 22,75 00000 x xx 0 F0 xx S 560 R
8LSC64.ee045ffgg-2
Synchronous motor, external cooling, size 6, length 4, rated speed 4500 rpm
8LSC64.ee045ffgg-3
S4 4500 19,63 00000 x xx 0 F0 xx S 560 R
8LSC65.ee022ffgg-2
Synchronous motor, external cooling, size 6, length 5, rated speed 2200 rpm
8LSC65.ee022ffgg-3
S4 2200 28,6 00000 x xx 0 F0 xx S 560 R0
8LSC65.ee030ffgg-2
Synchronous motor, external cooling, size 6, length 5, rated speed 3000 rpm
8LSC65.ee030ffgg-3
S4 3000 27,3 00000 x xx 0 F0 xx S 560 R0
8LSC65.ee045ffgg-2
Synchronous motor, external cooling, size 6, length 5, rated speed 4500 rpm
8LSC65.ee045ffgg-3
S4 4500 15,86 00000 x xx 0 F0 xx S 560 R
8LSC66.ee022ffgg-2
Synchronous motor, external cooling, size 6, length 6, rated speed 2200 rpm
8LSC66.ee022ffgg-3
S4 2200 31,85 00000 x xx 0 F0 xx S 560 R
8LSC66.ee030ffgg-2
Synchronous motor, external cooling, size 6, length 6, rated speed 3000 rpm
8LSC66.ee030ffgg-3
S4 3000 30,55 00000 x xx 0 F0 xx S 560 R
8LSC66.ee045ffgg-2
Synchronous motor, external cooling, size 6, length 6, rated speed 4500 rpm
8LSC66.ee045ffgg-3
S4 4500 19,5 00000 x xx 0 F0 xx S 560 R0

贝加莱伺服电机贝加莱8LS同步电机冷却类型C尺寸7：
8LSC73.ee022ffgg-3
S5 2200 28.5 00000 x xx 0 F0 xx S 560 R0
8LSC73.ee030ffgg-3
S5 3000 26.8 00000 x xx 0 F0 xx S 560 R0
8LSC73.ee045ffgg-3
S5 4500 21.5 00000 x xx 0 F0 xx S 560 R0
8LSC74.ee022ffgg-3
S5 2200 36.8 00000 x xx 0 F0 xx S 560 R0
8LSC74.ee030ffgg-3
S5 3000 34 00000 x xx 0 F0 xx S 560 R0
8LSC75.ee022ffgg-3
S5 2200 45.5 00000 x xx 0 F0 xx S 560 R0
8LSC75.ee030ffgg-3
S5 3000 41 00000 x xx 0 F0 xx S 560 R0
8LSC76.ee015ffgg-3
S5 1500 66 00000 x xx 0 F0 xx S 560 R0

贝加莱伺服电机贝加莱8LS同步电机冷却类型C尺寸8：
8LSC83.ee015ffgg-0
Synchronous motor, external cooling, size 8, length 3, rated speed 1500 rpm
8LSC83.ee020ffgg-0
Synchronous motor, external cooling, size 8, length 3, rated speed 2000 rpm
8LSC83.ee022ffgg-0
Synchronous motor, external cooling, size 8, length 3, rated speed 2200 rpm
8LSC83.ee030ffgg-0
Synchronous motor, external cooling, size 8, length 3, rated speed 3000 rpm
8LSC84.ee011ffgg-0
Synchronous motor, external cooling, size 8, length 4, rated speed 1100 rpm
8LSC84.ee015ffgg-0
Synchronous motor, external cooling, size 8, length 4, rated speed 1500 rpm
8LSC84.ee020ffgg-0
Synchronous motor, external cooling, size 8, length 4, rated speed 2000 rpm
8LSC84.ee022ffgg-0
Synchronous motor, external cooling, size 8, length 4, rated speed 2200 rpm
8LSC84.ee030ffgg-0
Synchronous motor, external cooling, size 8, length 4, rated speed 3000 rpm
8LSC85.ee015ffgg-0
Synchronous motor, external cooling, size 8, length 5, rated speed 1500 rpm
8LSC85.ee020ffgg-0
Synchronous motor, external cooling, size 8, length 5, rated speed 2000 rpm
8LSC86.ee015ffgg-0
Synchronous motor, external cooling, size 8, length 6, rated speed 1500 rpm
8LSC86.ee020ffgg-0
Synchronous motor, external cooling, size 8, length 6, rated speed 2000 rpm

贝加莱伺服电机贝加莱8LS同步电机附件：
8BPE0001.0000-00
17-pin EnDat connector, SpeedTec, IP67, crimp contact included in delivery: 17x 0.14-1.0 mm2,...
8BPM0001.0000-00
8-pin motor connector, SpeedTec, IP67, crimp contact included in delivery: 4x 0.35-2.5 mm2 + 4x 0.14-1.0 mm2,...
8BPM0002.0000-00
8-pin motor connector, SpeedTec, IP67, crimp contact included in delivery: 4x 2.5-4.0 mm2 + 4x 0.14-1.0 mm2,...
8BPM0003.0000-00
8-pin motor connector, SpeedTec, IP67, crimp contact included in delivery: 4x 1.5-10.0 mm2 + 4x 0.35-2.5 mm2,...
8BPR0001.0000-00
12-pin resolver connector, SpeedTec, IP67, crimp contact included in
