4PP420.0571-B5

贝加莱8LS同步电机特点：
8LS三相同步电机
8LS系列三相同步电机是专为需要高动态特性和定位精度以及紧凑型结构应用而开发的的永磁电子换向同步电机。

NdFeB永磁体
正弦EnDat编码器或旋变器作为反馈单元
现在可用功能安全编码器
三相星型连接
尺寸紧凑，重量轻巧
良好的转子构造，使转动惯量***小化，保证了优异的动态特性
高负载能力/峰值扭矩
扭矩脉动低
高速时的高动态扭矩
寿命长，除轴承外所有电机部件免磨损
定子产生的功耗通过外壳直接转移到法兰上
预紧的深沟球轴承两端密封并油脂润滑
完整的电机产品线，堵转扭矩范围从0.2 Nm至115 Nm
采用两个SpeedTEC圆形插头进行电气连接
由ACOPOS伺服驱动器或ACOPOSmulti驱动系统控制

8LS三相同步电机不能直接与电源连接，它们只能与ACOPOS伺服驱动器或ACOPOSmulti驱动系统组合起来进行工作！

贝加莱8LS同步电机首选伺服电机类型：
8LSA25.D8060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 40 mm; j6 A fit...
8LSA25.D8060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.800 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 40 mm; j6 A fit...
8LSA25.D9060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 40 mm; j6 A fit...
8LSA25.D9060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 40 mm; j6 fit...
8LSA25.R0060D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 40 mm; j6 A fit...
8LSA25.R0060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 40 mm; j6 A fit...
8LSA25.R0060D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 0.600 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 40 mm; j6 A fit...
8LSA25.R0060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 0.800 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 40 mm; j6 A fit...
8LSA35.DA030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm;...
8LSA35.DA030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DA060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DA060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DB030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DB030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DB060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.DB060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA35.EA030D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA030D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA060D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA060D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EA060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB030D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB030D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB060D000-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB060D200-0
Synchronous motor; number of pole pairs: 2 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.EB060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.R2030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; without holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.R2030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.R2060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA35.R2060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 2.300 Nm; motor with holding brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA37.DA030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DA030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DA060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DA060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DB030S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DB030S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DB060S000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.DB060S200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 80 mm; j6 A fit...
8LSA37.R2030D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA37.R2030D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 3000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA37.R2060D000-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; no brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA37.R2060D200-3
Synchronous motor; number of pole pairs: 4 pairs; nominal speed: 6000 rpm stall torque: 3.600 Nm; with brake; smooth shaft; angled connector (swivel); centering diameter 80 mm; j6 A fit...
8LSA44.DA030S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 3000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
8LSA44.DA060S000-3
Synchronous motor; number of pole pairs: 5 pairs; nominal speed: 6000 rpm stall torque: 6.000 Nm; no brake; smooth shaft; angled connector (swivel) single-cable solution; centering diameter 95 mm; j6 A fit...
4PP420.0571-B5贝加莱触摸屏

卓越的品质，性能强劲且操作安全
在工业环境中要保证正确操作就必须充分重视电磁兼容EMC。除了标准中规定的测试以外，还必须在恶劣的环境中进行现场测试。测试结果充分证明了在实验室和实际操作中优异的测试指标。设备中还内置了CE指南规定的滤波器。
计算机辅助模型运用已测量的电流和温度预测出整个系统的热能。从而实现了***大化系统性能。
ACOPOS伺服驱动会用到电机嵌入式参数芯片上的信息，这些信息包括相关的机电一体化数据。因此不再需要繁复且容易出错的人工设置参数，启动时间也大大减少。在维护期间，提供相关的必要数据并快速定位事故原因。
ACOPOS伺服系列也提供带部分涂层的电路板。这些产品具有相同的规格，但在防尘，防潮等环境影响下更加强大。
4PP420.0571-B5贝加莱触摸屏
特价工业贝加莱 B&R BR2003系统产品
7CP570.60-1 1) 2003系列CPU,Celeron 300, 64MB DRAM, 512KB SRAM, 24VDC, 15W供电,可更换应用存贮卡:CompactFlash,
1个aPCI插槽,1个USB接口,一个100 Base-T 100 Ethernet接口
7CP476-020.9 2) 2003系列CPU,可扩展,750KB SRAM, 1.5MB FlashPROM, 24VDC, 11.8W供电,1个RS232接口,1个CAN接口
7CP476-010.9 2003系列CPU,可扩展,750KB SRAM, 1.5MB FlashPROM, 24VDC, 12.15W供电,1个RS232接口,1个CAN接口
7CP476.60-1 2003系列CPU,750KB SRAM, 1.5MB Flash PROM, 24VDC, 12.5W供电,1个RS232和CAN接口:电隔离
7CP774.60-1 2003系列CPU,100KB SRAM,512KB FlashPROM,100-240VAC, 12.6W供电,1个RS232和CAN接口
7CP474.60-2 2003系列CPU,750KB SRAM,512KB FlashPROM,24VAC,12.6W供电,1个RS232和CAN接口
7CP770.60-1 2003系列CPU,100KB SRAM,256KB FlashPROM,100-240VAC,14W供电,1个RS232和CAN接口
7CP470.60-2 2003系列CPU,350KB SRAM,512KB FlashPROM,24VAC,14W供电,1个RS232和CAN接口
7CP430.60-1
7EX270.50-1 2003系列CAN总线控制器,24VDC, 4W供电,1个CAN接口,电隔离,可连接网络
7EX290.50-1 2003系列X2X Link总线控制器,24VDC,3.2W供电,1个X2X Link接口,电隔离
7EX470.50-1 2003系列CAN总线控制器,24VDC, 14.5W供电,2个CAN接口,电隔离,可连接网络
7EX770.50-1 2003系列CAN总线控制器,100-240VDC,14.5W供电,2个CAN接口,电隔离,可连接网络
7EX481.50-1 2003系列ETHERNET Powerlink总线控制器,1个ETHERNET Powerlink接口,24VDC,电隔离
7EX484.50-1 2003系列ETHERNET Powerlink总线控制器,4个ETHERNET Powerlink接口,24VDC,电隔离
7AF101.7 2003系列适配器模块,4个插槽,用于旋入式模块
7AF104.7 2003系列高速适配器模块,4个插槽,用于旋入式模块
7DI435.7 2003系列数字量输入模块,8路输入,24VDC, 1ms,漏式/源式
7DI439.7 2003系列数字量输入模块,16路输入,24VDC,1ms,漏式/源式
7DI439.72 2003系列数字量输入模块,16路输入,24VDC,1ms,漏式/源式,2个电隔离输入组
7DI645.7 2003系列数字量输入模块,8路输入,100-240VDC,50ms
7DM435.7 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM438.72 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM465.7 2003系列数字量混合模块,16路输入24VDC,1ms,漏式,16路晶体管输出24VDC,0.5A
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7DI135.70 2003系列数字量输入模块,4路输入24VDC,漏式,输入增量式编码器信号: 50 kHz,输入事件计数器信号:  100 kHz,1个比较器信号输出
7DI138.70 2003系列数字量输入模块,10路输入24VDC,漏式,输入2个事件计数器信号,输入频率20kHz
7DI140.70 2003系列数字量输入模块,10路输入24VDC,漏式,输入2个事件计数器信号或者带方向的位置测量
7DO435.7 2003系列数字量输出模块,8路FET输出,24 VDC,2A. 输出端也可设置成输入端
7DO720.7 2003系列数字量输出模块,8路继电器输出,240VAC/30VDC,2A
7DO721.7 2003系列数字量输出模块,4路继电器输出,240VAC/24VDC,4A
7DO722.7 2003系列数字量输出模块,8路继电器输出,240VAC/24VDC,2.5A
7DM435.7 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM438.72 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM465.7 2003系列数字量混合模块,16路输入24VDC,1ms,漏式,16路晶体管输出24VDC,0.5A
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7MM424.70-1 2003系列电机模块,4个电机数字量输出等级,24VDC,3A/50°C,***大启动电流10A (max.50 ms)
7MM432.70-1 2003系列电机跨接模块,2个电机(H)跨接,10-30VDC@4A,峰值电流***高8A(max.2s),集成电流调节器
7DO135.70 2003系列数字量输出模块,4路FET输出,12-24VDC,0.1A,旋入式模块
7DO138.70 2003系列数字量输出模块,8路输出端24VDC,0.5 A,短路保护,热过载保护,旋入式模块
7DO139.70 2003系列数字量输出模块,8路输出端,12-24VDC,0.5A,短路保护,热过载保护,旋入式模块
7DO164 .70 2003系列数字量输出模块,4路FET输出 48-24VDC,0.05A,零交叉测试,旋入式模块
7DM435.7 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM438.72 2003系列数字量混合模块,8路输入24VDC,1ms,漏式/源式,8路晶体管输出24VDC,0.5A
7DM465.7 2003系列数字量混合模块,16路输入24VDC,1ms,漏式,16路晶体管输出24VDC,0.5A
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7AI261.7 2003系列模拟量输入模块,1个全桥附值的输入通道,24-bit,旋入式模块
7AI294.7 2003系列模拟量输入模块,4路输入,电位器测量,13-bit,旋入式模块
7AI351.70 2003系列模拟量输入模块,1个输入,+/10 V或0-20 mA, 12-bit +符号位,旋入式模块
7AI354.70 2003系列模拟量输入模块,4路输入,+/10V,12-bit+符号位,旋入式模块
7AI774.70 2003系列模拟量输入模块,4路输入,0-20 mA,12-bit,旋入式模块
7AM351.70 2003系列模拟量混合模块,1路输入,±10V,16-bit,1路输出,±10V,16-bit,旋入式模块
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7AO352.70 2003系列模拟量输出模块,2个输出,+/10V或0-20mA,12-bit,旋入式模块
7AM351.70 2003系列模拟量混合模块,1路输入,±10V,16-bit,1路输出,±10V,16-bit,旋入式模块
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7AM351.70 2003系列模拟量混合模块,1路输入,±10V,16-bit,1路输出,±10V,16-bit,旋入式模块
7AT324.70 2003系列模拟量输入模块,4路温度输入(2线连接),KTY10-50 - +150°C,KTY84 -40 - +300°C, PT100 -200 - +850°C
7AT352.70 2003系列模拟量输入模块,2路输入,PT100(3线连接技术),-200 - +850°C,旋入式模块
7AT664.70 2003系列模拟量输入模块,4路输入,热电偶,-270 - +1,372°C,旋入式模块
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7MM424.70-1 2003系列电机控制,4个电机数字量输出等级,
24VDC,3A/50°C,***大启动电流10A (max.50 ms)
7MM432.70-1 2003系列电机桥模块,2个电机(H)跨接,
10-30VDC@4A,峰值电流***高8A(max.2s),集成电流调节器
3IF613.9 2005系列接口模块,3个RS232接口,插在CPU和IF模块上
3IF621.9 2005系列接口模块,1个RS485/RS422接口,1个CAN接口,电隔离,可连接网络,插在CPU和IF模块上
3IF622.9 2005系列接口模块,1个RS232接口,2个RS485/RS422接口:  电隔离,可连接网络,插在CPU和IF模块上
3IF661.9 2005系列接口模块,1个RS485接口,电隔离,可连接网络,传输协议: Profibus DP,插在CPU和IF模块上
3IF671.9 2005系列接口模块,1个RS232接口,1个RS485/RS422接口,电隔离,可连接网络,1个CAN接口,电隔离,可连接网络,插在CPU和IF模块上
3IF672.9 2005系列接口模块,1个RS232接口,2个CAN接口: 电隔离,可连接网络,插在CPU和IF模块上
3IF681.86 2005系列接口模块,1个RS232接口,1个Ethernet接口,带10BASE-T双绞线RJ45接头
3IF686.9 2005系列接口模块,1个ETHERNET Powerlink接口,管理器或控制器功能,电隔离
7IF311.7 2003系列接口模块,1个RS232接口,旋入式模块
7IF321.7 2003系列接口模块,1个RS485/RS422接口,电隔离,可连接网络,旋入式模块
7IF361.70-1 2003系列接口模块,1个RS485接口,电隔离,可连接网络,传输协议: Profibus DP,旋入式模块
7CM211.7 2003系列混合模块,8路输入,24VDC, 4ms,漏式,1/2个通道用于计数器信号或2个增量式编码器,20kHz
7CM411.70-1 2003系列混合模块,3路输入,24VDC,50 kHz,漏式,1/2个通道用于计数器信号,增量式编码器,2个晶体管输出,24VDC,0.5A
7DI135.70 2003系列数字量输入模块,4路输入24VDC,漏式,输入增量式编码器信号: 50 kHz,输入事件计数器信号:  100 kHz,1个比较器信号输出
7DI138.70 2003系列数字量输入模块,10路输入24VDC,漏式,输入2个事件计数器信号,输入频率20kHz
7DI140.70 2003系列数字量输入模块,10路输入24VDC,漏式,输入2个事件计数器信号或者带方向的位置测量
7NC161.7 2003系列编码器模块，输入频率100kHz，增量式或绝对式，32-bit，编码器供电5VDC或24VDC,旋入式模块
7BP702.0 2003系列模块底板可安装2个模块
7BP703.0 2003系列模块底板可安装3个模块
7BP704.0 2003系列模块底板可安装4个模块
7BP705.0 2003系列模块底板可安装5个模块
7BP706.0 2003系列模块底板可安装6个模块
7BP707.0 2003系列模块底板可安装7个模块
7BP708.0 2003系列模块底板可安装8个模块
7BP709.0 2003系列模块底板可安装9个模块
7BP710.0 2003系列模块底板可安装10个模块
7BP701.1 2003系统模块底板可安装1个模块，仅包括右挡板
7BP702.1 2003系统模块底板可安装2个模块，仅包括右挡板
7ME770.5 2003系列配置内存用于CAN总线控制器
4PP420.0571-B5贝加莱触摸屏
