3500/53-03-00

3500/53超速电子检测系统

描述

本特利内华达州的电子超速检测系统的3500系列机械检测系统提供了高度可靠、快速响

应、冗余的测速系统，专门用于为超速保护系统的一部分。它的设计是为了满足美国石

油学会标准670的要求和612属于超速保护。3500/53模块可以组合成一个二取二或二（推荐）系统。冗余电源在3500架包含超速检测系统的使用要求。



键相位输入
3500系统可以容纳四键相位传感器每机架安装两个3500/25键相位模块在rack2。3500/25是一个高度一半的模块，***多两键相位传感器各自提供了动力和终止。当应用程序需要键相位传感器，只需安装一个3500/25模块。从3500/25模块键相位信号（S）可以被路由到适当的监测模块通过3500架背板使用的速度，相位，跟踪滤波器，和其他测量。
1。超过四个键相位传感器时，必须使用在一个单一的机架，接触有关特殊的修改提供的细节工厂。

2。当使用2个3500/25模块时，它们必须被安装在同一个机架槽中，另一个则是另一个在同一个机架上的插槽中，一个是另一个的。
3500/53-03-00本特利超速电子监测系统
