| 品牌:力士乐 | | 型号:R900935732 | | 加工定制:否 | |
| 材质:铸铁 | | 连接形式:法兰 | | 类型:直动式 | |
| 适用介质:油品 | | 压力环境:常压 | | 工作温度:常温 | |
| 流动方向:单向 | | 介质温度:37 ℃ | | 工作压差:300 | |
| 适用范围:液压系统 | | | | | |
力士乐二通插装阀LC40A40D7X/ R900935732,德国REXROTH二通插装阀,购买进口液压、气动、自动化控制工业配件,
认准“上海韦米机电设备有限公司”,保证产品原厂原装,价格优惠,售后无忧,欢迎新老客户咨询采购!
插装阀在液压系统中的应用.
插装阀具有内阻小,结构简单,工作可靠,标准化程度高,对于大流量、高压力、较复杂的液压系统可以显著的减小尺寸和重量等特点;而实心胎硫化机组液压系统工作时需要大流量、高压力油,因而,此系统可以应用插装阀满足要求。
一、
插装阀的工作原理及特点
插装阀是另一类液压控制阀的统称。其基本核心元件是一种液控型、单控制口的装于油路主级中的两通液阻单元(故又称二通插装阀)。将一一个或若干个插入元件进行不同的组合,并配以相应的先导控制级,可以组成插装阀的各种控制功能单元。比如方向控制功能单元、压力控制单元、流量控制单元、复合控制功能单元。
插装阀具有以下特点:内阻小,适宜大流量工作,阀口多数采用锥面密封,因而泄漏小,对于乳化液等地粘度的工作介质也适宜,结构简单、工作可靠、标准化程度高;对于大流量、高压力、较复杂的液压系统可以显著的减小尺寸和重量。
其结构:先导阀,控制盖板,插装件。
它是由插入元件、控制盖板、通道块三大部分组成。插入元件有阀芯、阀套、弹簧和密封件组成;控制盖板上根据插装阀的不同控制功能,安装有相应的先导控制级元件;通道块既是嵌入插入元件及安装控制盖板的基础阀体,又是主油路和控制油路的连通体。其中A、B为主油路通口,C为控制油路通口。A、B、C油口的压力和作用面积分别为PA、PB、PC和A1、A2、A3,A3=A1+A2, Fs为弹簧作用力。
二通插装阀通过不同的盖板和各种先导阀组合,便可构成方向控制阀、压力控制阀和流量控制阀。
1、插装阀构成压力控制阀
根据插装阀的工作原理当PAA1+PBA2 >PCA3+FS时,阀芯开启,油路A、B接通。插装阀C14,当电磁阀得电时,插装阀C14的C口直接通油箱,其C口压力为零。由此可知油路A、B接通,当A口的压力大于弹簧力的时候,系统压力油回油箱,所以此插装阀起溢流阀的作用,控制油缸径油口压力。
2、插装阀构成方向控制阀
由液压动作程序表可知,同时得电,来控制主油缸上行运动。当两者同时得电时插装阀C11、C13的C口通油箱PA>FS时,A、B口直接相通,油液可从A流向B口;当只有一个电磁阀得电时,主油缸下行运动。其中C13的PA
3、插装阀构成流量控制阀
在阀的顶盖上有阀芯升高限位装置通过调节限位装置的位置,便可调节阀口通流截面的大小,从而调节了流量。通过调节流量,可调节主油缸的下行速度。此插装阀作节流阀。
三、
插装阀在液压系统的简单应用,通过更为复杂的组合,可以实现更多的液压阀的功能。通过组合,插装阀可作为压力控制阀(顺序阀、减压阀)、流量控制阀(单向节流阀、节流阀)、方向控制阀(调速阀、液控单向阀、两位两通换向阀等)以及复合阀。
力士乐二通插装阀LC40A40D7X/ R900935732
力士乐REXROTH二通插装阀
力士乐REXROTH逻辑元件-定向功能
力士乐REXROTH插装阀
力士乐REXROTH二通插装阀,定向功能LC
