7AT324.70

贝加莱8KS同步电机特点：
8KS三相同步电机
8KS系列三相同步电机是专为需要高动态特性和定位精度应用而开发的的永磁电子换向同步电机。

额定功率高达140 kW
风扇冷却并优化水冷
正弦EnDat编码器或旋变器作为反馈单元
可用功能安全编码器
三相星型连接
高负载能力/峰值扭矩
扭矩脉动低
高速时的高动态扭矩
寿命长，除轴承外所有电机部件免磨损
电源通过接线盒连接，编码器通过SpeedTEC或 ITEC圆形连接器连接
由ACOPOS伺服驱动器或ACOPOSmulti驱动系统控制

8KS三相同步电机不能直接与电源连接，它们只能与ACOPOS伺服驱动器或ACOPOSmulti驱动系统组合起来进行工作！

8KS三相同步电机可以配置各种不同的编码器系统。通常，它们配有Heidenhain EnDat 编码器。根据具体的应用，用户可以选择单圈或多圈光电式编码器。无需寻参过程或者附加测量系统便可运行。8KS三相同步电机也可以配置旋变器以适用于低精度和低速度的机械。

贝加莱8KS同步电机冷却类型C：
贝加莱8KS同步电机冷却类型C尺寸8：
8KSC82.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 1100 rpm;
8KSC82.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 1600 rpm;
8KSC82.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 2000 rpm;
8KSC82.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 2500 rpm;
8KSC82.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 2, nominal speed 3000 rpm;
8KSC84.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 1100 rpm;
8KSC84.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 1600 rpm;
8KSC84.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 2000 rpm;
8KSC84.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 2500 rpm;
8KSC84.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 4, nominal speed 3000 rpm;
8KSC85.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 1100 rpm;
8KSC85.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 1600 rpm;
8KSC85.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 2000 rpm;
8KSC85.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 2500 rpm;
8KSC85.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 5, nominal speed 3000 rpm;
8KSC86.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 1100 rpm;
8KSC86.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 1600 rpm;
8KSC86.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 2000 rpm;
8KSC86.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 2500 rpm;
8KSC86.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 8, length 6, nominal speed 3000 rpm;

贝加莱8KS同步电机冷却类型C尺寸9：
8KSC92.ee010ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 1000 rpm;
8KSC92.ee015ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 1500 rpm;
8KSC92.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 2000 rpm;
8KSC92.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 2500 rpm;
8KSC92.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 2, nominal speed 3000 rpm;
8KSC94.ee010ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 1000 rpm;
8KSC94.ee015ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 1500 rpm;
8KSC94.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 2000 rpm;
8KSC94.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 2500 rpm;
8KSC94.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 4, nominal speed 3000 rpm;
8KSC95.ee010ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 5, nominal speed 1000 rpm;
8KSC95.ee015ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 5, nominal speed 1500 rpm;
8KSC95.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 5, nominal speed 2000 rpm;
8KSC95.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 5, nominal speed 2500 rpm;
8KSC96.ee010ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 6, nominal speed 1000 rpm;
8KSC96.ee015ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 6, nominal speed 1500 rpm;
8KSC96.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, B-side foot mounting possible; size 9, length 6, nominal speed 2000 rpm;

贝加莱8KS同步电机冷却类型D：
贝加莱8KS同步电机冷却类型D尺寸8：
8KSD82.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 1100 rpm;
8KSD82.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 1600 rpm;
8KSD82.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 2000 rpm;
8KSD82.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 2500 rpm;
8KSD82.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 2, nominal speed 3000 rpm;
8KSD84.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 1100 rpm;
8KSD84.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 1600 rpm;
8KSD84.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 2000 rpm;
8KSD84.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 2500 rpm;
8KSD84.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 4, nominal speed 3000 rpm;
8KSD85.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 1100 rpm;
8KSD85.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 1600 rpm;
8KSD85.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 2000 rpm;
8KSD85.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 2500 rpm;
8KSD85.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 5, nominal speed 3000 rpm;
8KSD86.ee011ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 1100 rpm;
8KSD86.ee016ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 1600 rpm;
8KSD86.ee020ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 2000 rpm;
8KSD86.ee025ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 2500 rpm;
8KSD86.ee030ff00-0
Synchronous motor, external cooling; centrifugal fan, flange mounting, A and B side foot mounting; size 8, length 6, nominal speed 3000 rpm;
