3500/15-02-00-00

3500/15电源

描述

3500/15电源是半高的模块，必须安装在专门设计的槽的左侧的机架。3500/05机架可以

包含一个或两个电源供应器（任何的交流和/或直流的组合），或者提供一个完整的机架

。如果安装了，二次电源作为主电源的备份。在一个机架上安装2电源供应器时，下槽供

应器作为主要供给，上槽供应作为备用电源。拆卸或插入电源模块，只要有一个电源供

应器，就不会中断机架的运行。

3500/15电源接受了广泛的输入电压，并将其转换为可接受的电压由其他3500个模块使用

。三电源版本可与3500系列机械保护系统

如下：
交流电源

高压直流电源

低压直流电源



系统组件
架

3500架全尺寸19“环评railmount可用，面板开孔安装，隔板安装的版本。该机架为双电源供应槽和左大部分机架位置的机架接口模块，这些都是专门为这些模块保留的。剩下的14槽机架可以容纳任意组合的监测、显示、继电器、键相位模块、通信网关模块，所有模块插入机架的背板，包括一个主模块和I/O模块。输入/输出模块安装在机架安装系统后的机架上，并将其安装在舱壁安装系统的主要模块之上。

机架的深度是349毫米（13.75英寸）和NEMA 4，4X防水外壳，可在需要时为环保或净化空气用。
一个迷你机架（12“宽而不是19”），也可提供7个可用的监测插槽，而不是14。与它的较大的对应，左大部分插槽是保留的电源供应或供应和机架接口模块。迷你机架可安装在面板切口，使用一个可选的适配器板，19“环评安装导轨。舱壁安装不可用。
